Technical Specifications Breakdown
The FANUC A06B-6117-H209 operates with an input voltage of 283-339 VDC and a rated input power of 11 kW. It provides an output voltage range of 200-240 VAC, supporting output frequencies from 0.1 to 800 Hz. The module delivers a rated output current of 19A on both the L-axis and M-axis, making it suitable for dual-axis motion control applications. Its input frequency acceptance of 50/60 Hz ensures compatibility with global power grids.
Industry Applications
In CNC machining centers, the A06B-6117-H209 drives spindle and feed axes with precision, handling rapid acceleration and deceleration cycles. For robotic assembly lines, its dual 19A outputs enable coordinated motion of multiple joints, improving throughput.
Installation & Setup Guidance
Proper installation of the FANUC A06B-6117-H209 begins with verifying the DC input voltage (283-339 VDC) and ensuring the AC output connections match the motor specifications. Mount the module in a clean, well-ventilated enclosure to maintain airflow and prevent overheating. Use shielded cables for signal lines to minimize electromagnetic interference. Always confirm that the input frequency (50 or 60 Hz) aligns with your facility's power supply before energizing.
When Precision Motion Control Demands Unwavering Reliability
In high-stakes manufacturing environments, a servo amplifier failure can halt production lines and cause costly downtime. Engineered for complex automation systems, this module ensures precise control of servo motors, reducing the risk of unexpected stops.
Maintenance & Reliability
To maximize the service life of the A06B-6117-H209, schedule periodic inspections of cooling fans and air filters. Check for dust accumulation on heat sinks, as this can impair thermal performance. Monitor ambient conditions to stay within the 0°C to 55°C range and below 90% RH. Regular testing of output currents (19A per axis) under load helps detect early signs of component degradation, reducing unplanned downtime and extending operational reliability.
Buying Guide & Selection Advice
Before purchasing a FANUC A06B-6117-H209, verify that your system's DC bus voltage falls within the 283-339 VDC range and that the required output voltage (200-240 VAC) matches your motor specifications. Confirm the weight of 25.00 lbs (11.34 kg) for mounting considerations. AutoDCSTech offers this servo amplifier module with verified inventory and fast shipping, ensuring you get the exact part needed for your motion control upgrade or replacement.
What is the rated output current of the FANUC A06B-6117-H209?
The module provides 19A on both the L-axis and M-axis, enabling dual-axis servo control.
Can this servo amplifier operate in high-temperature environments?
Yes, it functions reliably in ambient temperatures from 0°C up to 55°C, making it suitable for demanding industrial settings.
What input voltage does the A06B-6117-H209 require?
It requires a DC input voltage between 283 and 339 VDC, with a rated input power of 11 kW.
Is the A06B-6117-H209 compatible with 60 Hz power systems?
Yes, the module accepts input frequencies of 50 or 60 Hz, ensuring global compatibility.
What is the weight of this servo amplifier module?
The FANUC A06B-6117-H209 weighs 25.00 lbs (11.34 kg), which should be accounted for during installation.
Availability & Condition at AutoDCSTech
| Part Number | A06B-6117-H209 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Japan |
