Product Overview
When CNC systems demand precise motion control, the FANUC A06B-6079-H301 Servo Amplifier delivers reliable performance. This triple-axis drive supports position, speed, and torque control, making it a versatile choice for complex machining tasks. Part of the A06B product line, this servo amplifier handles demanding applications with a rated power of 1.85 kW and a maximum output voltage of 230 V.
Technical Specifications Breakdown
The A06B-6079-H301 operates with a rated input voltage of 283-325 V at 50/60 Hz frequency. This input range ensures stable power delivery for consistent output. The amplifier provides a maximum output voltage of 230 V, sufficient for driving servo motors in CNC systems. Its rated power of 1.85 kW supports medium-duty applications without overloading.
Cooling is managed through an air-cooled system, which maintains optimal operating temperatures without complex liquid cooling. The unit operates reliably in environments from 0°C to 55°C, covering standard industrial conditions. With a weight of 15.00 lbs (6.80 kg), the amplifier is compact enough for vertical or wall-mounted installation.
Industry Applications
This servo amplifier excels in CNC machining centers, milling machines, and lathes that require coordinated motion across three axes. The triple-axis design simplifies wiring and reduces cabinet space compared to using three separate drives. For example, in a 3-axis CNC mill, the A06B-6079-H301 controls X, Y, and Z movements simultaneously, improving cycle times and surface finish.
In high-production environments, the integrated protection features—overload, overcurrent, and overvoltage—prevent costly downtime. These safeguards protect both the amplifier and connected motors, extending equipment life and reducing maintenance costs.
Installation & Setup Guidance
Mount the A06B-6079-H301 vertically or on a wall using the provided mounting points. Ensure adequate clearance around the unit for airflow, as the air-cooled system requires unobstructed ventilation. Connect the rated input voltage of 283-325 V to the designated terminals, observing proper phase and grounding. Use shielded cables for encoder and control signals to minimize electrical noise.
Configure the control type (position, speed, or torque) via the drive's parameter settings to match your application. For initial setup, verify all protection thresholds are set according to the motor and load specifications.
Maintenance & Reliability
Regular inspection of the cooling fan and air filters keeps the A06B-6079-H301 running efficiently. Dust buildup can impede airflow, so clean the exterior and vents periodically. Check all electrical connections for tightness and signs of corrosion. The unit's robust protection features reduce the risk of failure, but routine testing of overload and overcurrent functions ensures they remain operational.
Given the operating temperature range of 0°C to 55°C, avoid installing the amplifier near heat sources or in direct sunlight. Proper environmental control extends the service life of the drive and connected components.
Buying Guide
Before purchasing the FANUC A06B-6079-H301, verify that your CNC system requires a triple-axis servo amplifier with 1.85 kW rated power and 230 V output. Confirm the input voltage matches your facility's supply (283-325 V). SpareTechPLC stocks this model and can assist with availability and compatibility questions. Please verify current lifecycle status and availability with SpareTechPLC before ordering.
Frequently Asked Questions
Q: Does the A06B-6079-H301 support single-axis operation?
A: This model is a triple-axis drive designed to control three axes simultaneously. For single-axis applications, consider a single-axis servo amplifier from the same series.
Q: What is the maximum output voltage of this servo amplifier?
A: The maximum output voltage is 230 V, as specified in the technical data.
Q: Can I mount this amplifier horizontally?
A: The recommended mounting orientations are vertical or wall-mounted. Horizontal mounting may impede airflow and reduce cooling efficiency.
Q: What protection features does the A06B-6079-H301 include?
A: It includes overload, overcurrent, and overvoltage protection to safeguard the drive and connected equipment.
Q: What is the weight of this servo amplifier?
A: The unit weighs 15.00 lbs (6.80 kg), making it manageable for cabinet installation.
