Introduction
When your production line demands reliable variable frequency control for motors up to 5 HP, the FANUC VFS15-2037PM-W1 AC drive delivers consistent performance. This micro-drive, part of the Toshiba S15 series, provides precise speed regulation and energy efficiency for a wide range of industrial applications.
Technical Specifications Breakdown
The VFS15-2037PM-W1 is built around key parameters that ensure robust operation. The drive is rated for 5 horsepower and supports a full load current of 17.5 amps. It operates on a three-phase supply voltage of 230 VAC, making it suitable for standard low-voltage industrial networks. The unit weighs 2.2 kg and measures 15.0 cm x 14.0 cm x 17.0 cm, offering a compact footprint for panel mounting. The model includes a built-in basic filter (indicated by the 'M' in the part number) to reduce electrical noise, and an operation panel is provided for local control and monitoring.
Industry Applications
This AC drive excels in applications such as conveyor systems, pumps, and fans where variable speed control improves process efficiency. For example, in a material handling line, the VFS15-2037PM-W1 can adjust motor speed to match product flow, reducing mechanical stress and energy consumption. Its compact size allows easy integration into existing control cabinets.
Installation & Setup Guidance
When installing the VFS15-2037PM-W1, ensure the supply voltage matches the 230 VAC three-phase requirement. Mount the drive in a clean, dry location with adequate ventilation. Connect the motor leads to the output terminals, and use the provided operation panel for initial parameter configuration. Always follow local electrical codes and the manufacturer's manual for wiring details.
Maintenance & Reliability
Routine inspection of the drive's cooling fan and air filters helps maintain thermal performance. The built-in basic filter reduces harmonic distortion, extending the life of connected components. Periodically check all electrical connections for tightness. With proper care, this drive offers long-term reliability in demanding environments.
Compatibility & Integration
The VFS15-2037PM-W1 integrates seamlessly with standard three-phase induction motors. It accepts analog and digital control signals from PLCs or other automation controllers. The included operation panel simplifies setup and diagnostics, making it a practical choice for both new installations and retrofit projects.
Selection Guide & Purchasing Advice
Before purchasing, verify that the motor's full load current does not exceed the drive's 17.5 amp rating. Confirm the supply voltage is 230 VAC three-phase. The VFS15-2037PM-W1 is available from SpareTechPLC, a trusted supplier of industrial automation components. Contact our team to check current stock and lead times.
Frequently Asked Questions
Q: What is the horsepower rating of the VFS15-2037PM-W1?
A: The drive is rated for 5 horsepower.
Q: What is the full load current capacity?
A: It supports 17.5 full load amps.
Q: What input voltage does this drive require?
A: It requires a three-phase 230 VAC supply.
Q: Does the drive include an operation panel?
A: Yes, the 'P' in the part number indicates a provided operation panel.
Q: What is the weight of the VFS15-2037PM-W1?
A: The unit weighs 2.2 kg.
