GE Fanuc IC200CPU005 Versamax CPU Module with 64 KB Memory

Technical Specifications Breakdown

Key parameters for the IC200CPU005 are listed below for quick reference:

Industry Applications

Discrete Manufacturing Control

In automotive assembly lines, the IC200CPU005 handles up to 2048 I/O points, coordinating sensors and actuators across multiple stations. Its 0.8 msec/k boolean execution speed ensures fast response for pick-and-place operations.

Process Monitoring

For chemical batch processes, the RS-485 serial port allows daisy-chaining multiple remote I/O units over long distances, reducing wiring costs while maintaining reliable data acquisition.

Installation and Setup Guidance

Mount the CPU on a DIN rail using the appropriate base. Ensure the open enclosure is protected from water sprays and conductive contaminants. Connect the serial port to a programmer or PC via RS-232 or RS-485 for initial configuration. The module draws 35 milliamps at 5 V without a serial port converter, and 135 milliamps with one. Ground the unit properly to prevent electrical damage.

Maintenance and Reliability

Inspect the removable battery annually to ensure backup power for RAM and the real-time clock. Keep the area around the module clear to allow convection cooling—do not obstruct airflow. Operate within 0-60 degrees Celsius to maintain reliability.

Reliable Control for Complex Automation

The GE Fanuc IC200CPU005 CPU module for the Versamax series solved the issue with its dedicated RS-232 and RS-485 serial ports, enabling stable connection to programmers and PCs for configuration. This component provides the processing power needed for up to 64 modules and 2048 input/output points, making it a robust choice for distributed control systems.

Compatibility and Integration

The IC200CPU005 integrates with the Versamax series using the internal network via RS-232 and RS-485. It supports up to 64 modules in a single system, making it suitable for medium-scale automation projects.

Selection Guide and Purchasing Advice

When selecting a CPU for your Versamax system, consider the I/O count and communication needs. The IC200CPU005 offers 2048 points and dual serial ports. For current lifecycle status and availability, contact AutoDCSTech before ordering. We stock this module and can advise on compatibility.

Troubleshooting and Common Issues

If the CPU fails to communicate, check the serial port connection and converter usage. A loss of battery power may cause RAM data loss—replace the battery promptly. Overheating can occur if airflow is blocked; verify convection cooling paths are clear.
