Introduction to the 6FX8002-2DC10-1FA0
When a motion control system suffers from signal interference or cable failure, the 6FX8002-2DC10-1FA0 provides a reliable solution. This pre-assembled DRIVE-CLiQ cable from Siemens is engineered for precise motor encoder communication in industrial automation. It features a 50-meter length and robust construction, ensuring stable data transfer between the converter and motor.
Key Features and Technical Specifications
The 6FX8002-2DC10-1FA0 is a signal cable with a DRIVE-CLiQ design. It includes a 24 V plug with RJ45 connectors, rated IP20 on the module side and IP67 on the motor side. This cable is part of the MOTION-CONNECT 800PLUS series, released for lengths up to 75 meters. The cable outer diameter is 7.1 mm, and it is available in a 50-meter length.
- Connector type: RJ45 DRIVE-CLiQ on both engine and converter sides.
- Test voltage for signal conductors: 500 V rms.
- Rated voltage for power conductors: 30 V (per EN 50395).
- Smallest bending radius (fixed installation): 35 mm.
- Smallest bending radius (flexible installation): 75 mm.
- Maximum traversing velocity: 300 m/min.
- Maximum acceleration (horizontal): 50 m/s².
- Tensile stress (fixed installation): 50 N/mm².
- Tensile stress (flexible installation): 20 N/mm².
- Torsional stress: 30 per meter.
Applications and Use Cases
Its flexible installation rating supports continuous motion applications, while the fixed installation variant suits stationary wiring. The IP67 motor-side connector ensures durability in harsh environments, reducing downtime caused by connector failure.
Installation and Setup
During installation, respect the minimum bending radii to prevent internal damage. For fixed installations, use a bending radius of at least 35 mm; for flexible paths, maintain 75 mm. Ensure the cable is not subjected to tensile stress beyond the specified limits. Proper routing and strain relief extend cable life and maintain signal integrity.
Maintenance and Reliability
Regularly inspect the cable for cuts, abrasions, or kinks, especially near connection points. The cable sheath is made of PUR, which offers oil resistance and flame resistance per EN 60332-1-1 to 1-3. This reduces the risk of fire propagation in industrial settings. Periodic checks of connector tightness prevent intermittent signals.
Compatibility and Integration
The 6FX8002-2DC10-1FA0 is designed for Siemens DRIVE-CLiQ systems, ensuring seamless integration with compatible converters and motors. The RJ45 connectors simplify plug-and-play setup. Always verify compatibility with your specific drive model before ordering.
Troubleshooting Common Issues
If signal errors occur, first check the cable for physical damage. Verify that the bending radius is within limits, as excessive flexing can break internal conductors. Confirm that the cable is not stretched beyond its tensile rating. For persistent issues, test with a known-good cable to isolate the problem.
Product Support and Availability
The 6FX8002-2DC10-1FA0 is available from AutoDCSTech. Contact our team to confirm stock and lead times.
Availability & Condition at AutoDCSTech
| Part Number | 6FX8002-2DC10-1FA0 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Germany |
