Honeywell MSOX3024T Mixed Signal Oscilloscope 200 MHz 4+16 Channels

Technical Specifications Breakdown

Key parameters for the MSOX3024T are listed below for quick reference:

Industry Applications

Embedded System Debugging

The 200 MHz bandwidth captures fast edges, while the 1,000,000 wfms/s update rate helps reveal rare glitches that slower instruments miss.

Power Electronics Testing

When testing switch-mode power supplies, you need to observe both control signals and power-stage waveforms. The MSOX3024T allows simultaneous viewing of analog voltages and digital gate drives, enabling rapid loop analysis. The 4 Mpts memory ensures long captures without losing resolution.

Automotive ECU Validation

Automotive engineers can use the 16 digital channels to monitor sensor outputs and actuator commands. The zone touch triggering isolates specific events in seconds, reducing test time. This model's upgradability—adding bandwidth, a 20 MHz arbitrary waveform generator, or serial trigger—makes it a flexible bench tool.

Installation & Setup Guidance

Before connecting the instrument, verify that the included N2843A 500 MHz 10:1 attenuation passive probe matches each analog channel. Connect the N2756A 16 digital channel MSO cable to the digital input port. Use the multi-language interface to select your preferred language from the 16 supported options. For accurate measurements, perform a self-calibration after power-on and ensure proper grounding.

Maintenance & Reliability

This oscilloscope comes with a factory 3-year warranty and a 3-year calibration interval. To maintain accuracy, store the unit in a clean, dry environment. Inspect probes and cables periodically for damage. The certificate of calibration is included, confirming traceability. For long-term reliability, avoid exposing the unit to extreme temperatures or humidity.

Why settle for limited visibility when you can capture 1,000,000 waveforms per second?

Engineers often struggle to isolate intermittent faults in complex mixed-signal designs. The Honeywell MSOX3024T Mixed Signal Oscilloscope addresses this challenge with a 200 MHz bandwidth, 4 analog channels, and 16 digital channels. This combination lets you view analog and digital signals simultaneously, making it easier to correlate timing issues and debug embedded systems.

Compatibility & Integration

The MSOX3024T is fully upgradable. You can add bandwidth, a 20 MHz arbitrary waveform generator, a 3-digit voltmeter, serial trigger, and analysis & mask testing at any time. This flexibility ensures the instrument grows with your needs. The included documentation CD provides localized user’s guide, service guide, and programmer’s manual, making integration into automated test systems straightforward.

Selection Guide & Purchasing Advice

When selecting a mixed signal oscilloscope, consider your current and future bandwidth needs. The MSOX3024T offers 200 MHz, which suits most embedded and power electronics applications. If you need higher bandwidth later, the upgrade path protects your investment. AutoDCSTech supplies this model with all standard accessories, including the N2843A probe per channel and the N2756A MSO cable. Contact AutoDCSTech to verify lifecycle status and availability before ordering.
