GE Fanuc IC200NDR001 Versamax Nano PLC Controller 24 VDC

Technical Specifications Breakdown

Key parameters for the IC200NDR001 are listed below for quick reference:

Industry Applications

In conveyor sorting systems, the IC200NDR001 manages up to 10 I/O points to control actuators and sensors, leveraging its 1280 global references for flexible programming. For packaging machinery, the 28 MHz processor and 1.2 microsecond boolean speed enable precise timing for label applicators and sealers. The controller also supports multi-drop configurations via an RS-485 adapter, suiting distributed control in water treatment or material handling.

Installation and Setup Guidance

Mount the controller on a DIN rail in a clean, dry enclosure. Use Versa Pro version 1.1 software for configuration and programming. Connect the 24 VDC power supply ensuring polarity matches. The RJ-45 port on the front provides local area network connectivity for programming and monitoring. No removable terminal strips are present, so wire directly to the fixed terminals. Set ambient temperature between 0 and 55 degrees Celsius for normal operation.

Maintenance and Reliability

The IC200NDR001 is designed for long service life with relay contacts rated for 200,000 electrical operations at 2 Amps. The power supply holdup time of 10 milliseconds ensures ride-through during brief power dips. The controller can withstand shocks of 15 G for up to 11 milliseconds and vibrations from 57 to 500 Hertz. Inspect wiring and ambient conditions periodically to maintain reliability.

Compact Control for Discrete Automation

The GE Fanuc IC200NDR001 is a Nano PLC controller from the Versamax series, engineered for small-scale discrete automation tasks. Its 28 MHz processor delivers a boolean execution speed of 1.2 microseconds, ensuring responsive control in high-speed sorting or packaging lines.

Compatibility and Integration

This controller uses SNP, SNP X, and RTU slave protocols for communication. It is modem-compatible and supports multi-drop configurations with an RS-485 adapter. The Flash memory stores programs without battery backup. The CE marking indicates compliance with relevant European directives. For comparison, similar Nano PLCs often lack the 1280 global references or the 28 MHz processor speed found here.

Selection Guide and Purchasing Advice

When selecting a Nano PLC for discrete control, consider the I/O count, processor speed, and communication needs. The IC200NDR001 offers 6 inputs, 4 outputs, and SNP/RTU protocols. Contact AutoDCSTech to verify current lifecycle status and availability before ordering. Our team can help match this controller to your application requirements.
