IC670MDL641: 48VDC Field Control Input Module 16 Point
The IC670MDL641 is the 48VDC Field Control Input Module 16 Point covered on this page. The attribute that decides whether it fits the existing installation without modification is 48 Volts DC.
The reason to specify this exact variant is 48vdc field control input module 16 point. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. 48vdc field control input module 16 point sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 48 Volts DC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC670MDL641 |
| Series | Field Control |
| Part Number | IC670MDL641 |
| Rated Voltage | 48 Volts DC |
| Input Voltage Range | 0 to 60 Volts DC |
| Number of Inputs | 16 |
| Current (User Input) | 2.5 milli Amps per point at 48 Volts DC |
| Isolation Voltage | 250 Volts AC (continuous) / 1500 Volts AC for 1 minute |
| Input Impedance | 10K minimum |
| On-state Voltage | +34 to +60 Volts (positive logic) / -34 to -60 Volts (negative logic) |
| Off-state Voltage | 0 to +10 Volts (positive logic) / 0 to -10 Volts (negative logic) |
| On-state Current | 0.3 to 3 milliamps |
| Off-state Current | 0 to 0.5 milliamps |
| Response Time (On) | 6 milliseconds (typical) / 10 milliseconds (maximum) |
| Response Time (Off) | 6 milliseconds (typical) / 20 milliseconds (maximum) |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-fanuc-ic670mdl640-24vdc-discrete-input-module-16-points-field-control | confirm the configuration against your installation |
| ge-fanuc-ic670mdl642-125vdc-positive-negative-logic-input-module-field-cont | confirm the configuration against your installation |
| ge-fanuc-ic670mdl643-5-12-vdc-positive-negative-input-module-for-field-cont | confirm the configuration against your installation |
| ge-ic670mdl644-24vdc-positive-negative-fast-input-module-16-points | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC670MDL641 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
