IC670MDL642: 125VDC Positive/Negative Logic Input Module Field
The IC670MDL642 is the 125VDC Positive/Negative Logic Input Module Field covered on this page. The attribute that decides whether it fits the existing installation without modification is 125 Volts DC.
This configuration's 125vdc positive/negative logic input module field is the attribute that drives the replacement decision. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. 125vdc positive/negative logic input module field sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 125 Volts DC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC670MDL642 |
| Series | Field Control |
| Part Number | IC670MDL642 |
| Rated Voltage | 125 Volts DC |
| Input Voltage Range | 0 to 150 Volts DC |
| Number of Inputs | 16 |
| Current (User Input) | 2.5 milli Amps per point at 125 Volts DC |
| Isolation Voltage | 250 Volts AC (continuous) / 1500 Volts AC for 1 minute |
| Input Impedance | 40K minimum |
| On-state Voltage | +79 to +150 Volts (positive logic) / -79 to -150 Volts (negative logic) |
| Off-state Voltage | 0 to +30 Volts (positive logic) / 0 to -30 Volts (negative logic) |
| On-state Current | 0.3 to 3 milliamps |
| Off-state Current | 0 to 0.5 milliamps |
| Response Time (On) | 6 milliseconds (typical) / 10 milliseconds (maximum) |
| Response Time (Off) | 6 milliseconds (typical) / 20 milliseconds (maximum) |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-fanuc-ic670mdl640-24vdc-discrete-input-module-16-points-field-control | confirm the configuration against your installation |
| ge-fanuc-ic670mdl641-48vdc-field-control-input-module-16-point | confirm the configuration against your installation |
| ge-fanuc-ic670mdl643-5-12-vdc-positive-negative-input-module-for-field-cont | confirm the configuration against your installation |
| ge-ic670mdl644-24vdc-positive-negative-fast-input-module-16-points | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC670MDL642 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
