IC695CMM002: Communications Module
The IC695CMM002 is the Communications Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 0.7 Amps at 3.3 VDC, 0.115 Amps at 5 VDC.
This configuration's communications module is the attribute that drives the replacement decision. A communication or network module is judged by the protocol it carries and the bus it joins, not by its catalogue headline. communications module sets which controllers and field devices it can bridge, and the isolation and termination it provides. Matching 0.7 Amps at 3.3 VDC, 0.115 Amps at 5 VDC against the existing network topology avoids a module that fits the rack but cannot talk to the rest of the system.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC695CMM002 |
| Series | PACSystem RX3i |
| Part Number | IC695CMM002 |
| Product Type | Communications Module |
| Serial Ports | Two (2) RS232 / RS422 / RS485 |
| Interface | RJ-45 |
| Protocols | MODBUS Master, MODBUS Slave, CCM Slave, DNP3 Master, DNP3 Slave, Serial I/O |
| Baud Rates | 1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K |
| Power | 0.7 Amps at 3.3 VDC, 0.115 Amps at 5 VDC |
| Operating Temperature | 0 to 60 °C |
| Isolation | Port to Port 500 VDC continuous, 710 VDC for 1 min |
| Max Overvoltage | +/-25 VDC |
| Status LEDs | Module OK, Port Fault, Port Status |
| Data Bits | 7, 8 |
| Stop Bits | 1, 2 |
| Parity | Even, odd, none |
