900G03-0202: AC Digital Input Module 16 Channel
The 900G03-0202 is the AC Digital Input Module 16 Channel covered on this page. The attribute that decides whether it fits the existing installation without modification is 80 VAC to 264 VAC.
This configuration's ac digital input module 16 channel is the attribute that drives the replacement decision. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. ac digital input module 16 channel sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 80 VAC to 264 VAC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | Honeywell |
| Brand | Honeywell |
| Part Number | 900G03-0202 |
| Inputs per module | 16 (sinking) |
| Input Voltage Range | 80 VAC to 264 VAC |
| Peak Voltage | 264 VAC |
| AC Frequency | 47 Hz to 63 Hz |
| Galvanic Isolation | 2 groups of 8 inputs (350VAC max.) |
| ON Voltage Level | 75 VAC |
| OFF Voltage Level | 20 VAC |
| Input Impedance | 48 K ohms nominal |
| Input Current | 1 mA nominal @ 120 VAC, 60 Hz |
| Minimum ON Current | 0.3 mA |
| Maximum OFF Current | 0.2 mA |
| OFF to ON response time | 4 ms + 1.5-line cycles maximum |
| ON to OFF response time | 4 ms + 2-line cycles maximum |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| honeywell-900g01-0202-digital-input-module-16-channel-contact-type | confirm the configuration against your installation |
| honeywell-900g04-0101-digital-input-module-120-240-vac-125vdc | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | 900G03-0202 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
