Technical Specifications Breakdown
Key parameters for the 1792D-CBFM are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Product Line | 1792D ArmorBlock MaXum I/O |
| Part Number | 1792D-CBFM |
| Component Type | Cable Base |
| Supported Media | KwikLink™ flat media |
| Terminal Type | Screw Terminal |
| Casing | Plastic |
| Sealing Rating | IP67 |
| Weight | 3.00 lbs (1.36 kg) |
| Approximate Dimensions | 120 mm x 68.6 mm |
| Standards | EN 50081-2, EN 50082-2 |
| Compliance | CE, EU, EEA |
Industry Applications
Automotive Assembly Lines
In automotive plants, sensors and actuators are spread across welding, painting, and final assembly zones. The 1792D-CBFM cable base connects ArmorBlock MaXum I/O modules to KwikLink flat media, reducing wiring complexity. Its IP67 sealing rating allows placement near washdown stations without concern for water ingress.
Material Handling & Conveyor Systems
Conveyor networks in warehouses and distribution centers require robust connections that resist dust and accidental impacts. The screw terminals of this cable base provide a vibration-resistant hold, while the plastic casing keeps weight low—only 3.00 lbs (1.36 kg)—simplifying installation on moving equipment.
Food & Beverage Processing
With IP67 protection and compliance with EN 50081-2 and EN 50082-2 EMC standards, the 1792D-CBFM is suitable for food processing environments where frequent cleaning with high-pressure hoses occurs. The KwikLink flat media interface maintains signal quality even in electrically noisy areas.
Installation & Setup Guidance
Mount the cable base in a location that avoids excessive bending of the KwikLink flat media. Use Phillips-type screws (as specified) for secure fastening of the cable to the terminal block. Ensure the screw terminals are tightened to the manufacturer’s recommended torque (not provided here—refer to the product manual). The unit has no integral enclosure, so it must be installed within an overall system enclosure or panel that meets the environmental requirements of your application.
Maintenance & Reliability
Periodically inspect the screw terminals for signs of corrosion or loosening, especially in high-vibration or humid environments. The IP67 rating means the unit is protected against dust ingress and temporary immersion in water, but regular visual checks of the plastic casing for cracks or wear are recommended. No internal components are user-serviceable; if the cable base fails, replace the entire 1792D-CBFM unit.
Reliable Cable Base for ArmorBlock MaXum I/O
When building a distributed I/O network in harsh environments, the connection between your field devices and the control system must withstand moisture, dust, and vibration. The Allen-Bradley 1792D-CBFM cable base delivers that reliability as part of the ArmorBlock MaXum I/O series. Designed specifically for KwikLink™ flat media, this component provides a secure, screw-terminal interface that simplifies wiring while maintaining signal integrity.
Compatibility & Integration
The 1792D-CBFM is designed exclusively for the ArmorBlock MaXum I/O series and KwikLink flat media. It interfaces directly with compatible ArmorBlock modules to form a distributed I/O node. The screw terminals accept field wiring, while the KwikLink connection carries power and communication signals. Ensure your system controller supports the KwikLink protocol (typically DeviceNet-based) before integration.
Selection Guide & Purchasing Advice
When ordering a replacement or new installation, verify that your existing ArmorBlock MaXum I/O modules require the cable base form factor. The 1792D-CBFM is an original Allen-Bradley component, ensuring fit and reliability. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 1792D-CBFM |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
