900G32-0301: DC Digital Input Module 32 Channel
The 900G32-0301 is the DC Digital Input Module 32 Channel covered on this page. The attribute that decides whether it fits the existing installation without modification is 10 VDC to 32 VDC.
On this unit dc digital input module 32 channel is the figure that decides fit and function. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. dc digital input module 32 channel sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 10 VDC to 32 VDC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | Honeywell |
| Brand | Honeywell |
| Part Number | 900G32-0301 |
| Inputs per module | 32 (sinking) |
| Input Voltage Range | 10 VDC to 32 VDC |
| Peak Voltage | 32 VDC |
| Galvanic Isolation | 2 groups of 16 inputs (30VDC max.) |
| ON Voltage Level | 9.5 VDC minimum |
| OFF Voltage Level | 3.5 VDC maximum |
| Input Impedance | 6.9 K ohms nominal |
| Input Current | 1.7 mA @ 12 VDC, 3.5 mA @ 24 VDC nominal |
| Minimum ON Current | 1.0 mA |
| Maximum OFF Current | 0.7 mA |
| OFF to ON response time | 5 ms max |
| ON to OFF response time | 5 ms max |
| Operating /Storage Temperature | -40 to 70°C /-40 to 85°C Extended Operating Temperature |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| honeywell-900g32-0001-hc900-digital-input-card-24-vdc-32-channel | confirm the configuration against your installation |
| honeywell-900g32-0101-32-channel-digital-input-module-24vdc | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | 900G32-0301 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
