Mitsubishi FX2N-128MT-001 Fx2n Series Programmable Controller Overview

Product Introduction

This MPU main unit provides maximum flexibility and control capability for a wide range of applications. With a total of 128 I/O channels, it handles complex processes efficiently.

Technical Specifications Breakdown

The FX2N-128MT-001 offers a robust set of specifications. It features 64 input points and 64 output points, all transistor type. Power supply voltage is DC24V, with a power consumption of 100VA. The unit weighs 1.8 kg and measures 350x90x87 mm (WxHxD). Built-in 8K capacity RAM memory is expandable to 16K, and CPU arithmetic processing speed reaches 0.08 µs per basic instruction.

Industry Applications

Its transistor output type supports high-speed positioning with 2-axis independent 20kHz capability. Applications include packaging machinery, material handling, and assembly lines where precise control and quick response are essential.

Installation & Setup Guidance

Install the FX2N-128MT-001 in a clean, dry environment. Connect input and output expansion modules or special function modules on the right side of the unit. The quick-disconnect terminal block simplifies maintenance and cable replacement. Ensure DC24V power supply is stable and within specifications.

Maintenance & Reliability

Regular inspection of connections and environmental conditions ensures long service life. The unit's design supports easy maintenance with quick-disconnect terminal blocks. Verify proper operation periodically and follow manufacturer guidelines for cleaning and care. This approach minimizes downtime and extends equipment life.

Compatibility & Integration

The FX2N-128MT-001 integrates with FX2N series expansion modules and special function modules. It supports up to 256 points when using CC-Link remote I/O. The basic unit includes 2 analog input points and 1 analog output point, with options for voltage (DC0-10V) or current (DC4-20mA) signals.

Selection Guide & Purchasing Advice

Before ordering, verify that the FX2N-128MT-001 meets your I/O count and output type requirements. Consider the need for expansion modules or special adapters. AutoDCSTech offers this model and can assist with availability and replacement options. Please confirm lifecycle status before purchasing.
