ProSoft PLX32-EIP-PND: ProSoft PLX32 EIP PND EtherNet/IP to PROFINET Gateway
The ProSoft PLX32-EIP-PND is the ProSoft PLX32 EIP PND EtherNet/IP to PROFINET Gateway covered on this page. The attribute that decides whether it fits the existing installation without modification is -25°C to 70°C.
On this unit prosoft plx32 eip pnd ethernet/ip to profinet gateway is the figure that decides fit and function. A communication or network module is judged by the protocol it carries and the bus it joins, not by its catalogue headline. prosoft plx32 eip pnd ethernet/ip to profinet gateway sets which controllers and field devices it can bridge, and the isolation and termination it provides. Matching -25°C to 70°C against the existing network topology avoids a module that fits the rack but cannot talk to the rest of the system.
| Feature | Specification |
|---|---|
| Manufacturer | ProSoft |
| Brand | ProSoft |
| Part Number | ProSoft PLX32-EIP-PND |
| Power Supply | 24 VDC nominal (10-36 VDC allowed) |
| Current Load | 300 mA @ 24 VDC |
| Operating Temperature | -25°C to 70°C |
| Ethernet Ports | 2 x 10/100 Mbit RJ45 |
| Class 1 I/O Connections | 8 |
| Class 3 Client Connections | 2 connected, 1 unconnected |
| PROFINET I/O Data | 1440 bytes in/out |
| Dimensions | 5.38 x 1.99 x 4.38 in |
· Last updated:
Availability & Condition at AutoDCSTech
| Part Number | ProSoft PLX32-EIP-PND |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
