Technical Specifications Breakdown
Key parameters for the BMXRWSC016M are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | Memory Card |
| Memory Capacity | 16 MB |
| Compatible Modules | BMXNOE0100, BMXNOE0110 |
| Web Server | Transparent ready class C30 |
| Net Weight | 0.004 lb(US) (0.002 kg) |
| Package 1 Dimensions (H x W x L) | 0.31 x 4.88 x 5.71 in (0.800 x 12.400 x 14.500 cm) |
| Package 1 Weight | 0.952 oz (27.000 g) |
Industry Applications for the Memory Card
1. Firmware Storage for Network Modules
The BMXRWSC016M stores firmware files for BMXNOE0100 and BMXNOE0110 modules, enabling quick field upgrades without external tools. This reduces downtime during system updates.
2. Web Server Content Hosting
With Transparent ready class C30 support, this card hosts web server files for remote monitoring and diagnostics. Engineers access real-time data via standard browsers, improving troubleshooting efficiency.
3. Configuration Backup in Harsh Environments
In manufacturing plants with frequent power fluctuations, the non-volatile SD flash memory retains configuration data reliably. This prevents data loss and speeds recovery after outages.
Installation & Setup Guidance
Insert the BMXRWSC016M into the SD card slot of a compatible BMXNOE0100 or BMXNOE0110 module. Ensure the module is powered off during insertion to avoid data corruption. After power-up, verify card recognition via the module's web interface or configuration software. For firmware updates, copy the binary file to the card's root directory and follow the module's update procedure. Always use the card with Schneider-approved modules only.
Maintenance & Reliability
The BMXRWSC016M requires no routine maintenance. However, periodically inspect the card and slot for dust or debris. Avoid exposure to extreme temperatures, moisture, or magnetic fields. The card's compact size (0.31 x 4.88 x 5.71 inches) allows installation in tight control cabinets. For long-term reliability, replace the card if write errors occur during firmware updates.
Overcoming Network Module Storage Constraints
In modern industrial automation, network modules like the BMXNOE0100 and BMXNOE0110 require reliable, compact storage for firmware updates, web server files, and configuration backups. Without adequate memory, engineers face downtime during upgrades or troubleshooting. The Schneider BMXRWSC016M SD flash memory card provides a dedicated 16MB storage solution designed specifically for Modicon M340 automation platforms, ensuring seamless operation and data retention.
Compatibility & Integration
This memory card is exclusively compatible with Modicon M340 network modules BMXNOE0100 and BMXNOE0110. It is not intended for use with other M340 modules or third-party hardware. Integration is straightforward: insert the card, power on, and configure via the module's web server.
Selection Guide & Purchasing Advice
When selecting a memory card for your Modicon M340 network module, ensure the capacity meets your storage needs. The BMXRWSC016M offers 16 MB, sufficient for firmware files and web content. For larger applications, verify compatibility with AutoDCSTech. We stock genuine Schneider parts with fast shipping. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Troubleshooting & Common Issues
If the module does not recognize the card, check that the card is fully inserted and the module is powered correctly. If the card was used previously, reformat it to FAT32 using a PC before reuse. Corrupted firmware files may cause boot failures; re-copy the file to the card. For persistent issues, test with a known-good BMXRWSC016M to isolate the fault.
Availability & Condition at AutoDCSTech
| Part Number | BMXRWSC016M |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
Datasheet & Downloads
Specification sheet for BMXRWSC016M. For lead time, condition and price, contact our team.
