Schneider TSXCANCBDD5 CANopen Cordset with SUB-D9 Connectors, 5m

Technical Specifications Breakdown

Key parameters for the TSXCANCBDD5 are listed below for quick reference:

Optimized for CANopen Fieldbus Applications

The TSXCANCBDD5 is engineered for use in CANopen networks, a widely adopted communication protocol in motion control, machine automation, and sensor/actuator networks. Its 5-meter length provides flexibility in cabinet-to-machine connections, while the molded female SUB-D9 connectors ensure secure and durable mating. The IP20 rating makes it suitable for protected indoor environments such as control panels and junction boxes.

Installation and Setup Guidance

When integrating the TSXCANCBDD5, ensure the female SUB-D9 connectors are properly aligned and tightened to avoid signal degradation. The cordset is designed for plug-and-play use, reducing commissioning time. Verify that the CANopen network terminator is correctly placed at the end of the bus segment. Avoid sharp bends or excessive tension on the cable to maintain signal integrity.

Maintenance and Reliability

The molded construction of the TSXCANCBDD5 provides strain relief and protection against dust ingress (IP20). Periodic inspection of the connectors for corrosion or damage is recommended, especially in environments with vibration or temperature fluctuations. No special maintenance tools are required; simply clean with a dry cloth if needed.

Reliable CANopen Bus Connectivity with the TSXCANCBDD5

Industrial automation networks demand robust and standardized cabling to ensure data integrity and system uptime. The Schneider TSXCANCBDD5 CANopen cordset delivers a pre-assembled, connection solution for CANopen fieldbus systems. Designed as a molded cordset with female SUB-D9 connectors, this accessory simplifies installation and reduces the risk of wiring errors.

Compatibility and Integration

This cordset is part of the Schneider CANopen range, ensuring seamless compatibility with Schneider PLCs, drives, and I/O modules that support CANopen communication. The standard SUB-D9 interface allows integration with third-party CANopen devices as well. Always verify the device's pinout configuration before connection.

Selection Guide and Purchasing Advice

When selecting a CANopen cordset, consider cable length, connector type, and environmental protection. The TSXCANCBDD5 offers a balanced solution for typical cabinet-to-machine distances. For longer runs, alternative lengths may be required. AutoDCSTech stocks the TSXCANCBDD5 and can provide lifecycle and availability information. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
