Product Overview
When your process control system demands reliable and flexible automation, the Schneider Electric TSXP574823M delivers a compact yet powerful solution. Part of the TSX Micro PLCs series, this unit handles 10 to 30 simple loops through its dedicated process control channels. A built-in RESET button provides a cold start when pressed, simplifying system resets and troubleshooting.
Technical Specifications Breakdown
The TSXP574823M offers robust memory and processing capabilities. It includes 48 Kwords of internal RAM for program and data storage. With a PCMCIA card, memory expands to 160 Kwords for programs and 2688 Kwords for additional data storage. The PLC supports up to 16 racks, accommodating up to 1024 discrete I/O and 80 analogue I/O. Execution time is 0.19 µs per Boolean instruction without a PCMCIA card, or 0.21 µs with one installed.
Industry Applications
This PLC excels in process control environments such as water treatment, food and beverage, and light manufacturing. Its 10 to 30 simple loop capacity makes it ideal for managing temperature, pressure, and flow control loops. The integrated Ethernet TCP/IP (RJ45, 10/100 Mbit/s) allows seamless integration into plant-wide networks, while the non-isolated serial link (2 female mini DIN, 19.2 kbit/s) connects to legacy devices.
Installation & Setup Guidance
Mount the TSXP574823M in a clean, dry cabinet away from vibration and extreme temperatures. Connect the serial link using standard mini-DIN cables and the Ethernet port with a shielded RJ45 cable. Use the RESET button to perform a cold start after initial configuration or after a major fault. Ensure the PCMCIA memory card is properly inserted before powering on to avoid data corruption.
Maintenance & Reliability
Regularly inspect the front panel LEDs for operational status. The five LEDs provide quick visual feedback. Periodically verify that the PCMCIA card connections are secure. Keep the unit free of dust and moisture to ensure long-term reliability. The TSXP574823M is designed for continuous operation in industrial environments, minimizing downtime.
Compatibility & Integration
The TSXP574823M integrates with Schneider TSX Micro racks and I/O modules. It supports one fieldbus module (none if CANopen is used), up to four AS-Interface bus modules, and one CANopen network. The two PCMCIA slots allow for memory extension or communication cards. This PLC works with Schneider PL7 Pro software for programming and configuration.
Selection Guide & Purchasing Advice
Before ordering, verify that your system requires a TSX Micro PLC with 10 to 30 process control loops and 48 Kwords internal RAM. Confirm that the integrated serial and Ethernet connections match your network architecture. SpareTechPLC offers the TSXP574823M with fast shipping and expert support. Contact us to confirm availability and lifecycle status.
Frequently Asked Questions
Q: What is the execution time of the TSXP574823M?
A: The execution time is 0.19 µs per Boolean instruction without a PCMCIA card, and 0.21 µs with one installed.
Q: How many process control channels does this PLC support?
A: It supports 10 up to 30 simple loops for process control.
Q: What types of memory expansion are available?
A: The PLC has two PCMCIA slots. One supports memory extension cards (up to 160 Kwords program, 2688 Kwords data), and the other can accept a communication card or a 4 Mb SRAM memory extension card.
Q: Can the TSXP574823M connect to Ethernet networks?
A: Yes, it has an integrated Ethernet TCP/IP connection via RJ45 at 10/100 Mbit/s.
Q: What is the discrete I/O capacity?
A: The PLC can process up to 1024 discrete I/O and 80 analogue I/O.
