Schneider TSXSUP1011 Power Supply for TSX Micro PLCs

Technical Specifications Breakdown

Key parameters for the TSXSUP1011 are listed below for quick reference:

Industry Applications and Operational ROI

Its ability to accept both AC and DC input simplifies inventory and installation in mixed-voltage environments. The overload and short-circuit protection reduces the risk of costly downtime and component damage, directly improving operational ROI. By choosing a dedicated power supply with CE marking, you ensure compliance with European safety standards, which is critical for export-oriented or regulated industries.

Installation and Setup Guidance

Mount the TSXSUP1011 securely on a standard DIN rail within the control cabinet. Ensure the ambient temperature stays within the 0 to 60°C operating range for reliable performance. Connect the 24 V AC or DC input to the designated terminals, observing correct polarity for DC input. The output provides 24 V DC at 1A to power your PLC and peripherals. Always verify that the total load does not exceed the rated output current. The LED indicator confirms power status at a glance.

Maintenance and Reliability

Periodically inspect the enclosed housing for dust accumulation and ensure ventilation around the unit is unobstructed. Although the power supply is protected against overloads and short circuits, routine checks of input voltage stability and load current help prevent unexpected failures. The wide storage temperature range (-25 to 85°C) allows for safe warehousing in various climates.

Reliable Power for Your TSX Micro PLC System

When building or maintaining a TSX Micro PLCs-based automation system, a stable and protected power supply is non-negotiable. The Schneider Electric TSXSUP1011 is a standalone, enclosed power supply designed specifically to meet the demands of these controllers. It converts a 24 V AC or DC input into a regulated 24 V DC output, delivering up to 1A of current. This component is engineered to protect your investment with built-in overload and short-circuit protection, ensuring uptime in critical applications.

Compatibility and Integration

This unit is part of the TSX Micro PLCs product line from Schneider Electric, ensuring seamless integration with TSX Micro controllers and associated I/O modules. Its standalone configuration means it can be used in new builds or as a direct replacement in existing systems. The CE marking confirms conformity with applicable EU directives.

Selection Guide and Purchasing Advice

When selecting a power supply for your TSX Micro PLC system, verify that the input voltage matches your facility supply (24 V AC or DC) and that the 1A output current meets your load requirements. The TSXSUP1011 is a proven choice for reliable, protected power. AutoDCSTech stocks this unit and can advise on lifecycle status and availability. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
