Product Overview
When machinery protection demands precise, non-contact measurement of shaft vibration and position, the Vibro Meter 111-412-000-013-A1-B1-E010-F0-G000-H01 Proximity Measuring System delivers reliable performance. This eddy-current-based sensor from the vibro-meter® product line provides DC to 20 kHz frequency response and a measurement range of 2 or 4 mm, making it ideal for critical rotating equipment.
Technical Specifications Breakdown
The 111-412-000-013-A1-B1-E010-F0-G000-H01 operates with a transducer temperature range of -40 to +180°C (drift <5%) and short-term survival up to +220°C. The system includes a 1.0 m integral cable (E010) and a total system length of 1 m (H01). It features a standard M10 × 1 body thread (B1) and weighs 0.22 kg. The transducer head and integral cable are rated IP68 per IEC 60529, ensuring robust protection in harsh environments.
Industry Applications
This proximity measuring system excels in shaft relative vibration and gap/position measurement chains for machinery protection and condition monitoring. It integrates seamlessly with VM600Mk2/VM600 and VibroSmart® systems, supporting API 670 applications. Ex certified versions allow use in hazardous areas with potentially explosive atmospheres.
Installation & Setup Guidance
Mount the transducer with the M10 × 1 thread into a suitable mounting boss. Ensure the integral cable (1.0 m) is routed without sharp bends. Connect using the self-locking miniature coaxial connectors, hand-tightening until locked. For Ex zones, verify the transducer and cable temperature range (-40 to +195°C) meets area classification requirements.
Maintenance & Reliability
The temperature-compensated design minimizes drift over the operating range. The stainless steel body (AISI 316L) and Torlon tip provide durability. For standard environments, periodic visual inspection of the cable and connector is sufficient. In Ex zones, follow the manufacturer's safety manual for inspection intervals. The IP68 rating protects against dust and immersion.
Compatibility & Integration
This system works with IQS900 signal conditioners that supply a high-frequency power source. It is ideal for use with VM600Mk2/VM600 and VibroSmart® machinery monitoring systems. The voltage or current output includes short-circuit protection, simplifying integration into existing monitoring networks.
Selection Guide & Purchasing Advice
Before ordering the 111-412-000-013-A1-B1-E010-F0-G000-H01, verify the required system length (1 m) and cable length (1.0 m) match your installation. Confirm the Ex certification needs for hazardous areas. SpareTechPLC stocks this Vibro Meter proximity system and can advise on compatible signal conditioners and accessories. Please verify current lifecycle status and availability with SpareTechPLC before ordering.
