Schneider 140CPU67160 Unity Hot Standby Processor

Redundancy Architecture in the Modicon Quantum Platform

The Schneider Electric 140CPU67160 is a Unity Hot Standby processor engineered for the Modicon Quantum automation platform. It operates at a clock frequency of 266 MHz and carries 1024 kB of internal RAM, with 512 kB allocated for data. This architecture supports process control and hot standby checks, enabling primary and secondary PLC synchronization over an optic fibre Hot Standby link rated for up to 4 km.

For engineers specifying redundant control, the 140CPU67160 delivers deterministic execution through a 1 ms master task and a 0.2 ms fast task. Instruction throughput reaches 10.28 Kinst/ms at 100% Boolean and 10.07 Kinst/ms at 65% Boolean with 35% numerical. These verified figures allow precise cycle-time budgeting before commissioning.

Electrical and Communication Specifications

The processor requires 2500 mA of bus current and provides integrated connections including one Modbus Plus port, one Modbus port, one USB port, and one MT-RJ multimode fiber optic connector for PLC interconnection. A female SUB-D 9 connector serves the Modbus Plus network, while an RJ45 connector handles the Modbus bus.

Local signaling includes a green LED for Ethernet activity and a red LED for Ethernet collision. The key switch controls memory port on/off functionality. For distributed I/O, the 140CPU67160 supports up to 63 stations on Modbus Plus and 31 stations via S908 remote I/O, with additional Ethernet Quantum and X80 remote I/O capacity.

I/O Capacity and Application Structure

Discrete I/O capacity reaches 31,744 inputs and 31,744 outputs for remote configurations, plus 8,000 inputs and 8,000 outputs per Modbus Plus distributed network. Analogue capacity includes 500 inputs and 500 outputs per Modbus Plus network, with 1,984 inputs and 1,984 outputs for remote arrangements. Local I/O remains forbidden in Hot Standby applications.

The application structure supports one cyclic or periodic master task, with fast, interrupt, and auxiliary tasks restricted in Hot Standby mode. Memory expands to 7,168 kB for program storage and 8 MB for file storage using PCMCIA cards. Six optional modules accommodate Ethernet, Modbus, Modbus Plus, Profibus DP, and Sy/Max protocols.

Certifications and Physical Data

The 140CPU67160 holds CE, UL, CSA, GOST, and Marine certifications, with HazLoc standards applicable. The unit ships from France with a GTIN of 3595863819380. Package dimensions measure 11.0 cm in height, 19.0 cm in width, and 32.5 cm in length, with a total weight of 1.447 kg.

For system integrators, these verified parameters support accurate panel layout and logistics planning. AutoDCSTech maintains engineering-grade precision in every part supplied, ensuring exact specification matching for Quantum platform deployments.

Frequently Asked Questions

What redundancy topology does the 140CPU67160 support?

The processor supports Hot Standby redundancy with primary and secondary PLC interconnection via MT-RJ multimode fiber optic cable up to 4 km. This configuration maintains process control continuity during failover events.

How many remote I/O stations can the 140CPU67160 manage?

The unit supports 31 stations via S908 remote I/O, 31 stations via Ethernet Quantum remote I/O, and 16 stations via Ethernet X80 remote I/O. Distributed Modbus Plus networks accommodate up to 63 stations.

What is the bus current requirement for this processor?

The 140CPU67160 requires 2500 mA of bus current. Verify backplane power budget against this figure when configuring the Quantum rack.

Which certifications does the 140CPU67160 carry?

The processor holds CE, UL, CSA, GOST, and Marine certifications, with HazLoc standards applicable. These verified approvals support deployment in industrial and marine environments.

Procurement Guidance

Engineers specifying the 140CPU67160 should confirm rack slot availability, as the processor occupies two slots. The 266 MHz clock and 1024 kB RAM configuration suit demanding process control applications requiring deterministic execution and redundancy. Contact AutoDCSTech with your exact requirements for precise matching.
