3500/15-07-07-00 Low Voltage DC Supply | Bently Nevada

Introduction to the 3500/15-07-07-00

In the evolving landscape of industrial automation, reliable power delivery remains the backbone of continuous operations. The 3500/15-07-07-00 from Bently Nevada addresses this need with a dedicated low voltage DC supply designed for the 3500 series monitoring platform. As part of the 3500/15 AC and DC power supplies family, this module ensures your critical machinery protection system receives stable power, minimizing downtime and safeguarding assets.

Engineered for both non-hazardous and hazardous environments, the 3500/15-07-07-00 offers flexibility and robustness. Its universal AC input capability simplifies installation across different sites, while its compact form factor fits seamlessly into existing racks. This power supply is a key component for any plant seeking to enhance operational reliability.

Key Features & Technical Specifications

The 3500/15-07-07-00 is built to deliver consistent performance under demanding conditions. Below are the core specifications extracted from the official datasheet:

• Model: 3500/15 Power Supply
• Power Supply Type: Low Voltage DC Supply (Type 07)
• Agency Approval Option: None (Option 00)
• Input Voltage (Universal AC): 110 to 220 Vac nominal; 85 to 264 Vac rms (non-hazardous); 85 to 250 Vac rms (hazardous)
• Input Frequency: 47 to 63 Hz
• Output Current: Low voltage DC 11.0 A (maximum)
• Front Panel LED: Supply OK LED indicates proper operation
• Operating Temperature: -30 °C to +65 °C
• Storage Temperature: -40 °C to +85 °C
• Humidity: 95% non-condensing

This power supply module occupies two half-height slots on the left side of the rack, and it supports redundant configurations by allowing two supplies in the same rack. The universal AC input design ensures compatibility with global power grids, reducing the need for additional converters.

Installation & Setup

Proper installation is critical to ensure the 3500/15-07-07-00 operates safely and effectively. The module fits into designated half-height slots, with the power input module (PIM) located directly behind it. Ensure that the rack is properly grounded and that all connections are secure before powering up.

For hazardous area installations, verify that the input voltage remains within the specified range of 85 to 250 Vac rms. The module is not compatible with legacy High Voltage AC or Low Voltage AC units, so confirm your system configuration beforehand. Always follow the manufacturer's installation manual for detailed wiring instructions.

Maintenance & Reliability

Regular inspection of the power supply is essential to maintain long-term reliability. The Supply OK LED provides a quick visual check of operational status. Periodically verify that the LED is illuminated and that there are no signs of overheating or physical damage.

Given the wide operating temperature range and high humidity tolerance, the 3500/15-07-07-00 is designed for harsh industrial environments. However, routine checks of ventilation and cleanliness can prevent premature failure. For any maintenance procedures, consult the official Bently Nevada documentation to ensure safety and compliance.

Compatibility & Integration

The 3500/15-07-07-00 is part of the Bently Nevada 3500 series, a widely adopted monitoring system in rotating machinery protection. It integrates seamlessly with other 3500 series modules, such as monitors and communication processors, to form a complete condition monitoring solution.

This power supply is designed for use with universal AC power input modules, ensuring a matched power delivery system. When planning your rack configuration, consider the power requirements of all modules to ensure the 3500/15-07-07-00 can handle the total load. For systems requiring redundancy, two power supplies can be installed simultaneously, providing failover capability.

Product Support & Availability

AutoDCSTech is your reliable supplier for the 3500/15-07-07-00. We offer competitive pricing and fast delivery to keep your operations running. Contact our team for availability and ordering information.
