6AV2128-3KB06-0AX1 10.1" HMI MTP1000 Unified Comfort Panel

Introduction to the 6AV2128-3KB06-0AX1

When your production line demands reliable, high-resolution operator interaction, the 6AV2128-3KB06-0AX1 from Siemens delivers. This MTP1000 Unified Comfort Panel combines a 10.1-inch widescreen TFT display with 16 million colors, ensuring clear visualization of complex processes. As part of the SIMATIC HMI family, it is engineered for seamless integration into industrial environments.

With a PROFINET interface and support for WinCC Unified Comfort V16, this panel is ready for modern automation architectures. Its multi-touch screen and robust design make it a versatile choice for machine builders and end users alike.

Key Features and Technical Specifications

The 6AV2128-3KB06-0AX1 is packed with features that enhance usability and performance. Below are the critical specifications extracted from the official datasheet:

• Display: 10.1-inch TFT, 1280 x 800 pixels, 16,777,216 colors
• Touch Operation: Multi-touch screen, numeric and alphanumeric onscreen keyboards
• Supply Voltage: 24 V DC (range 19.2 V to 28.8 V)
• Current Consumption: Rated 0.5 A, max 1.1 A
• Interfaces: 2 Industrial Ethernet (switch), 1 RS 422/485, 4 USB 3.1 Gen 1, 2 SD card slots
• Protocols: PROFINET, TCP/IP, DHCP, SNMP, DCP, LLDP, MRP
• Protection: IP65 front, IP20 rear; NEMA 4x front
• Ambient Temperature: 0 °C to 50 °C (vertical installation)
• Dimensions: 280 mm x 205 mm (front), depth 64 mm
• Weight: 2.1 kg

One standout feature is the backlight with 50,000 hours MTBF at 25 °C, which reduces maintenance frequency. The dimmable backlight (5-100%) also helps save energy and extend panel life.

Applications and Use Cases

The 6AV2128-3KB06-0AX1 is suited for a wide range of industrial applications, from machine control to process monitoring. Its IP65 front makes it ideal for harsh environments where dust and water ingress are concerns. The multi-touch capability allows operators to interact intuitively, reducing training time.

For example, in a packaging line, this HMI can display real-time production data, alarms, and recipes, enabling quick adjustments. Its PROFINET connectivity ensures seamless communication with PLCs and other devices, supporting efficient data exchange.

Installation and Setup

Mounting the 6AV2128-3KB06-0AX1 is straightforward. It supports both portrait and landscape orientations, with a maximum tilt angle of 35 degrees without external ventilation. The panel requires a 264 mm x 189 mm cutout and has an overall depth of 64 mm, making it suitable for standard enclosures.

When installing, ensure the ambient temperature stays within the specified range. For vertical installation, the operating temperature is 0 °C to 50 °C; at maximum tilt, it is 0 °C to 40 °C. Proper ventilation is crucial to maintain performance and longevity.

Maintenance and Reliability

Routine maintenance for the 6AV2128-3KB06-0AX1 is minimal due to its solid-state design. The LED backlight offers a long service life, but periodic inspection is recommended to verify brightness and touch response. Keep the front surface clean using a soft, dry cloth to avoid scratches.

The panel's hardware clock with retentive memory (typically 6 weeks backup) ensures time stamps survive power outages, which is vital for alarm logging. Regularly check the SD card slots and USB ports for dust accumulation to maintain reliable data storage.

Compatibility and Integration

This HMI is designed to work with Siemens WinCC Unified Comfort V16 and WinCC Unified PC Engineering (TIA Portal). It supports PROFINET, making it compatible with SIMATIC S7 controllers and other PROFINET devices. The integrated switch with 2 ports allows daisy-chaining without additional hardware.

For advanced applications, the panel supports JavaScript, enabling custom scripts. It also includes a web browser, media player, and Sm@rtServer for remote access, enhancing flexibility in system design.

Troubleshooting and Common Issues

If the display does not power on, first check the DC supply voltage (19.2 V to 28.8 V) and current draw (max 1.1 A). Ensure the panel is not exposed to temperatures above 50 °C, as this can cause shutdowns. For network issues, verify PROFINET cable connections and switch settings.

If the touch screen becomes unresponsive, recalibrate it via the operating system settings. For persistent problems, consult the Siemens documentation or contact AutoDCSTech for support.

Product Support and Availability

The 6AV2128-3KB06-0AX1 is available from AutoDCSTech, a trusted supplier of industrial automation parts. We ensure genuine Siemens products with reliable delivery. Contact our team for pricing and lead times.
