Why Choose the 9200-06-02-01-00 for Vibration Monitoring?
When unplanned downtime threatens your rotating machinery, accurate vibration measurement is non-negotiable. The 9200-06-02-01-00 from Bently Nevada delivers reliable casing vibration data in a compact, rugged package. This two-wire velocity seismoprobe transducer is engineered for continuous operation in demanding industrial environments, helping you detect issues before they escalate.
Key Features and Technical Specifications
The 9200-06-02-01-00 is a two-wire velocity seismoprobe transducer with a sensitivity of 20 mV/mm/s (500 mV/in/s), ±5% when properly terminated and oriented at the angle of calibration. Its dynamic operating range handles up to 2.54 mm (0.100 in) peak-to-peak maximum displacement, and the velocity range reaches 25 mm/s (1 in/s) at +22°C casing vibration at 100 Hz with a 10 kΩ load.
- Coil Resistance: 1.25 kΩ ±5%
- Locked Coil Inductance: 125 mH, typical
- Operating Temperature: -29°C to +121°C (-20°F to +250°F)
- Relative Humidity: Up to 95% noncondensing; 100% non-submerged when ordered with integral cable
- Case Material: Anodized aluminum A204
- Gasket Material: Neoprene
- Height: 102 mm (4 in) typical (depending on connector option)
- Diameter: 41 mm (1.6 in) typical
- Weight: 300 grams (10.5 ounces) typical
The transducer is dust and moisture resistant, ensuring dependable performance even in harsh conditions. Its mounting options include a 0° ±100° angle with a 10 Hz minimum operating frequency, a side-mount connector (no cable), and a circular mounting base with a 1/4-20 UNC stud.
Real-World Applications
In industries such as power generation, oil and gas, and manufacturing, the 9200-06-02-01-00 excels at monitoring casing vibration on pumps, motors, fans, and compressors. Its high sensitivity and wide dynamic range make it suitable for both低速 and high-speed machinery. For example, in a petrochemical plant, this transducer can help detect bearing wear early, preventing costly catastrophic failures.
Installation and Setup Guidance
Proper installation is critical for accurate readings. Mount the transducer securely to a flat, clean surface using the 1/4-20 UNC stud. Ensure the mounting angle matches the calibration orientation (0° ±100°). Connect the two-wire output across terminals A and B with a 10 kΩ load for optimal performance. Always follow the manufacturer's manual for detailed wiring and mounting instructions.
Maintenance and Reliability Tips
To maintain long-term reliability, periodically inspect the transducer for physical damage, loose mounting, or moisture ingress. Verify the output signal against a known reference to ensure calibration drift has not occurred. The anodized aluminum case and neoprene gasket provide robust protection, but regular checks are recommended, especially in high-vibration or high-humidity environments.
Compatibility and Integration
The 9200-06-02-01-00 is a two-wire transducer designed for direct connection to Bently Nevada monitoring systems. Its 20 mV/mm/s output is compatible with standard vibration monitoring modules. For integration details, refer to the official Bently Nevada documentation or contact AutoDCSTech for assistance.
Common Issues and Troubleshooting
If you experience erratic readings, first check the cable connections and termination resistance. A 10 kΩ load is required across terminals A and B. If the output is low, verify the mounting angle and that the transducer is not loose. For persistent issues, consult the manufacturer's troubleshooting guide.
Product Support and Availability
The 9200-06-02-01-00 is available from AutoDCSTech, a trusted industrial automation parts supplier. Each unit is new and original in factory packing, backed by a 12-month factory warranty. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
