What Is the ABB 3HAC031683-004 Cable Teach Pendant 30m?
When a production line stops due to a faulty robot pendant cable, every minute of downtime costs thousands. The ABB 3HAC031683-004 Cable Teach Pendant 30m provides a reliable solution: a 30-meter cable designed for teach pendant connectivity in ABB robotic systems. This spare part, part of the ABB Spare_Parts frame size, ensures operators can program and control robots from a safe distance without signal degradation.
Key Specifications
- Product ID: 3HAC031683-004
- ABB Type Designation: 30x30x11
- Catalog Description: Cable Teach Pendant 30m
- Product Net Weight: 3.02 kg
- Gross Weight: 3.44 kg
- Country of Origin: China
- Part Type: New
These specifications confirm the cable's length and weight, making it suitable for large robotic cells where mobility and reach are critical.
Industry Applications
In automotive assembly lines, the 30-meter cable allows technicians to walk around a robotic workcell while jogging the robot arm, verifying tool paths without being tethered to a control cabinet. In heavy manufacturing, the robust construction withstands repeated flexing and exposure to oils and coolants, reducing replacement frequency.
Installation & Setup Guidance
When installing the ABB 3HAC031683-004, ensure the cable is routed away from sharp edges and moving parts. Use cable carriers or drag chains to manage the 30-meter length and prevent kinking. Verify connector compatibility with your teach pendant model before final connection.
Maintenance & Reliability
Inspect the cable sheath periodically for cuts or abrasions, especially near connection points. Avoid exceeding the minimum bend radius during installation to extend service life. The 3.02 kg net weight indicates a durable construction that can handle daily industrial use.
Compatibility & Integration
This cable is designed for ABB teach pendants requiring a 30-meter connection. It integrates seamlessly with ABB robot controllers that accept the corresponding connector type. Always confirm your pendant model and controller revision before ordering.
Selection Guide & Purchasing Advice
Before purchasing the 3HAC031683-004, verify your existing teach pendant cable length and connector type. If your application requires a different length, contact SpareTechPLC for alternatives. SpareTechPLC stocks this item in warehouses in Menden (Germany), Shanghai (China), and Bergkamen (Germany), ensuring fast delivery.
Frequently Asked Questions
Q: What is the exact length of the ABB 3HAC031683-004 cable?
A: The catalog description specifies a 30-meter cable, suitable for large robotic workcells.
Q: Is this cable a new or refurbished part?
A: The 3HAC031683-004 is listed as a new part type, ensuring original factory performance.
Q: What is the weight of the cable?
A: The net weight is 3.02 kg, and the gross weight (including packaging) is 3.44 kg.
Q: Where is this product manufactured?
A: The country of origin is China, as per the ordering information.
Q: Can I use this cable with older ABB robot models?
A: Compatibility depends on the teach pendant connector. Verify your pendant model and controller revision before ordering.
