Allen-Bradley 150-FPP970B SMC Flex Power Pole for 970 Amp Soft Starters

Product Overview

The Allen-Bradley 150-FPP970B is a modularly constructed power pole designed for the SMC Flex smart motor controller family. It provides microprocessor-controlled starting for industrial 3-phase squirrel-cage induction motors. This B Series component is available as a replacement part for 970 Amps rated controllers. It comes supplied as a replacement assembly including the pole, an instruction manual, 2 screws, and connecting cables for the power modules.

Technical Specifications Breakdown

Key parameters for the 150-FPP970B are listed below for quick reference:

Industry Applications

Typical uses include conveyors, pumps, compressors, and fans in industries such as mining, water treatment, and manufacturing. The 800 HP rating and 970 Amp capacity make it suitable for heavy-duty motor control where soft starting reduces mechanical stress and inrush current.

Installation & Setup Guidance

When installing the 150-FPP970B, ensure the SMC Flex controller is de-energized and locked out. The replacement assembly includes 2 screws and connecting cables; follow the instruction manual for proper mounting and wiring. Verify that the line input voltage matches the 200 to 480 Volts AC range. This single-phase power pole can be wired for single-phase applications as per the manual.

Maintenance & Reliability

Periodically inspect the power pole for signs of wear or overheating. Keep the assembly clean and free of dust. The SMC Flex controller offers built-in protection features including power loss protection, voltage unbalance protection, under-voltage protection, over-voltage protection, stall protection, jam detection, and electronic motor overload protection. These features enhance overall system reliability.

Compatibility & Integration

The 150-FPP970B is designed for the SMC Flex smart motor controller family. The SMC Flex controllers offer built-in bypass, integral DPI communication, and troubleshooting and metering capabilities. They support multiple starting and stopping modes: Soft Start, Current Limit Start, Dual Ramp Full Voltage Linear Speed Acceleration, Preset Slow Speed, and Soft Stop. Application parameters are entered via a 5-button programming keypad and LCD screen. The controllers also include 4 fully programmable auxiliary contacts.

Selection Guide & Purchasing Advice

When selecting a replacement power pole, confirm that your SMC Flex controller is rated for 970 Amps and the line voltage is within 200 to 480 Volts AC. The 150-FPP970B is a Series B component. Please verify current lifecycle status and availability with AutoDCSTech before ordering. AutoDCSTech offers this genuine Allen-Bradley part with fast shipping and expert support.
