Allen-Bradley 1790D-T0V32 24V DC 32 Sinking Output Base Module

Technical Specifications Breakdown

Key parameters for the 1790D-T0V32 are listed below for quick reference:

Industry Applications

Packaging and Material Handling

In high-speed packaging lines, the 1790D-T0V32 controls multiple pneumatic valves and conveyor zone indicators. The 0.5 ms off-to-on delay ensures rapid response for precise product positioning. The 32-point density reduces the number of I/O modules needed, cutting wiring time and cabinet space.

Assembly and Test Stations

For automated assembly cells, this module drives solenoid banks and status lamps. The sinking output configuration simplifies integration with common 24V DC sensors and PLCs. The 4.0 A per common rating supports simultaneous activation of multiple outputs without derating.

Cost-Benefit & Operational ROI

Using a single 32-point module instead of four 8-point modules lowers hardware costs and reduces panel wiring labor. The photocoupler isolation (1250V ac rms) protects the logic side from field transients, minimizing downtime from I/O failures. The green LED indicators per point speed troubleshooting, further improving mean time to repair.

Installation & Setup Guidance

Mount the 1790D-T0V32 on a DIN rail or panel using the provided terminal block (M3.0 screws). Torque each screw to 7 lb-in maximum, using copper or copper-clad aluminum conductors. Connect the DeviceNet power supply at 24V DC nominal (11…28.8V DC range) and the field power supply within 10…28.8V DC. Wire sinking outputs to the load common (COM) per the 16 points/2 COM grouping. Ensure the total current per common does not exceed 4.0 A.

Maintenance & Reliability

Periodically inspect the terminal block connections for tightness and verify the green status LEDs illuminate when outputs are active. Keep the module free of dust and moisture to maintain isolation integrity. The photocoupler isolation provides long-term reliability, but routine checks of field wiring insulation are recommended.

Solving High-Density Output Challenges in Compact Machinery

Industrial engineers often face the challenge of controlling numerous discrete actuators—solenoids, indicator lights, or contactors—within a limited panel space. The Allen-Bradley 1790D-T0V32 24V DC 32 sinking output base module addresses this need by packing 32 nonisolated, sinking outputs into a single, compact unit. This module eliminates the need for multiple smaller output blocks, simplifying wiring and reducing enclosure footprint while maintaining reliable 24V DC control.

Compatibility & Integration

The 1790D-T0V32 is part of the Allen-Bradley Compact 1790D series and integrates with DeviceNet networks. It consumes 4 output bytes and produces 0 default input bytes (1 input with status). This module works with any DeviceNet master scanner, such as ControlLogix or CompactLogix, for seamless data exchange.

Selection Guide & Purchasing Advice

When selecting the 1790D-T0V32 for your project, verify that your application requires 32 sinking outputs at 24V DC with 0.5A per channel. For sourcing output needs, consider alternative modules. AutoDCSTech stocks this module and can advise on lifecycle status and availability. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Troubleshooting & Common Issues

If an output fails to energize, check the green LED: if off, verify the field power supply is within 10…28.8V DC and the output point is configured correctly in the DeviceNet scanner. If the LED is on but the load does not operate, measure the on-state voltage drop (max 0.5V DC) across the output. A higher drop may indicate a faulty output or excessive load current. For intermittent operation, inspect terminal block torque and wiring continuity.
