Technical Specifications Breakdown
Key parameters for the 1792D-0B4D are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | 4-Channel Sourcing Output Block |
| Network Protocol | DeviceNet |
| Power-Supply Voltage (I/O) | 24 V DC |
| Output Count | 4 Outputs |
| Max Current per Output | 2A |
| Module Total Current | 4 A Max Load |
| Output Leakage | ≤ 1.5 mA |
| Surge Current | 4 A (10 ms) |
| Housing Rating | IP67 |
| Weight | 0.88 lbs (0.40 kg) |
Industry Applications for the 1792D-0B4D
Packaging and Material Handling
In packaging lines, the 1792D-0B4D controls pneumatic actuators and conveyor diverters with its 2A per channel sourcing outputs. The IP67 rating allows direct mounting near washdown zones, eliminating the need for separate enclosures. The DeviceNet protocol enables seamless integration with PLCs for real-time control and diagnostics.
Automotive Assembly Stations
Automotive plants require modules that withstand coolant, oil, and metal shavings. This output block's sealed housing and robust connector system (M12 I/O & Network) ensure reliable operation in these harsh conditions. The built-in local logic allows for quick response to sensor inputs without burdening the main controller.
Installation and Setup Guidance
When installing the 1792D-0B4D, ensure the 24 V DC power supply is stable and within the specified voltage range. Use M12 connectors for both I/O and network connections to maintain the IP67 seal. Configure the DeviceNet node address using the rotary node selector before powering up. Verify that the total load current does not exceed 4A across all channels. For surge protection, confirm that transient loads stay within the 4A for 10 ms rating.
Maintenance and Reliability
The IP67 housing protects against dust ingress and temporary water immersion, making this module suitable for periodic washdown environments. Inspect M12 connectors annually for corrosion or damage. Check output leakage (≤ 1.5 mA) during routine maintenance to ensure efficient operation. No internal adjustments are required; the module is designed for long-term reliability with minimal intervention.
Industrial Output Control for Harsh Environments
In demanding industrial settings, reliable output control is critical to maintaining uptime and preventing costly failures. The Allen-Bradley 1792D-0B4D is a compact 4-channel sourcing output block from the ArmorBlock MaXum series, engineered to deliver consistent performance in environments where dust, moisture, and vibration are constant challenges. This module provides a robust solution for controlling actuators, valves, and indicators directly on the machine, reducing wiring complexity and improving system responsiveness.
Compatibility and Integration
This output block operates exclusively on DeviceNet networks. It is compatible with any DeviceNet master scanner from Allen-Bradley or other vendors. The M12 connector system simplifies cabling and reduces installation time. The built-in local logic allows standalone operation for simple control tasks, reducing load on the central PLC.
Selection Guide and Purchasing Advice
When selecting the 1792D-0B4D, confirm that your application requires 4 sourcing outputs with 2A per channel and a total load of 4A. Verify that your network infrastructure supports DeviceNet. For lifecycle status and availability, please verify with AutoDCSTech before ordering. AutoDCSTech offers this module along with compatible cables and connectors to ensure a complete solution.
Availability & Condition at AutoDCSTech
| Part Number | 1792D-0B4D |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
