Allen-Bradley 22B-B017C104 PowerFlex 40 AC Drive, 5 HP, 17.5 A, IP66

Technical Specifications Breakdown

Key parameters for the 22B-B017C104 are listed below for quick reference:

Industrial Applications and Benefits

The IP66/NEMA 4X enclosure allows direct mounting in wet or corrosive environments, such as food processing, chemical plants, or wastewater treatment. With RS-485 communication, it integrates easily into existing control networks for remote monitoring and adjustment. The keypad interface simplifies local programming and troubleshooting, reducing downtime.

Installation and Setup Guidance

Mount the drive on a flat, non-flammable surface using the panel mount design. Ensure adequate clearance for airflow around the IP66 enclosure. Connect 3-phase 240V AC power to the input terminals. Use the keypad to configure basic parameters like acceleration, deceleration, and motor nameplate data. For network integration, connect the RS-485 port to your control system using shielded twisted-pair cable. Always follow local electrical codes and the manufacturer's manual.

Maintenance and Reliability

The robust IP66/NEMA 4X enclosure minimizes maintenance needs by preventing ingress of dust and moisture. Periodically inspect the enclosure seals and cooling fins for debris. Operate the drive within its ambient temperature range to ensure long service life. The keypad allows quick diagnostics without opening the enclosure, preserving the environmental seal.

Robust AC Drive for Demanding Environments

The Allen-Bradley 22B-B017C104 is a PowerFlex 40 series AC drive designed for reliable motor control in harsh industrial settings. This controller delivers 5 Horsepower output with a current rating of 17.5 Amps, making it suitable for a wide range of applications.

Compatibility and Integration

The 22B-B017C104 communicates via RS-485 using the DSI protocol, enabling connection with Allen-Bradley controllers and other DSI-compatible devices. It supports integral communication cards for DeviceNet, EtherNet/IP, and ControlNet networks, providing flexible integration into diverse automation architectures. The drive also accommodates wireless communication systems for remote access.

Selection Guide and Purchasing Advice

When selecting the 22B-B017C104, verify that your motor's voltage and current ratings match the drive's 240V AC, 17.0 A output. This drive does not include a CE-compliant filter, so factor in external filtering if required for your region. Contact AutoDCSTech for current availability and lifecycle status before ordering.

Please verify current lifecycle status and availability with AutoDCSTech before ordering.
