Technical Specifications Breakdown
Key parameters for the 20F1ANC260JN0NNNNN are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Rated Voltage | 400V AC / 540V DC |
| Number Of Phases | 3-Phase |
| Rated Frequency | 60 Hz |
| Normal Duty Power | 132 kW |
| Normal Duty Output Current | 260 A |
| Heavy Duty Power | 110 kW |
| Heavy Duty Output Current | 205 A |
| Protection Category | IP00 |
| Frame Size | Frame 6 |
| Temperature Range | 0 to 40°C |
| Maximum Storage Humidity | 80% (non-condensing) |
| Maximum Operating Humidity | 80% (non-condensing) |
| Maximum Operating Altitude | 1000 meters above sea level |
| Weight | 125.00 lbs (56.70 kg) |
Real-World Applications
For example, in a cement plant, the 260 A output current handles large conveyors and crushers under normal duty cycles. In water treatment facilities, the 110 kW heavy duty capability ensures reliable pump control even during peak loads. The IP00 open-type design suits installation in ventilated cabinets, protecting the drive from dust while allowing heat dissipation.
Installation and Setup Guidance
Mount the drive in a clean, dry location with adequate airflow. The IP00 rating requires external protection from debris and moisture. Ensure the supply voltage matches the rated 400V AC / 540V DC three-phase input. Use appropriately sized cables for 260 A continuous current. Follow the PowerFlex 753 manual for proper grounding and EMC filtering. The CM jumper is pre-installed for common mode filtering.
Maintenance and Reliability
Inspect the drive periodically for dust accumulation on heatsinks and fans. Operate within the 0 to 40°C ambient temperature range to avoid thermal derating. Maintain humidity below 80% non-condensing to prevent corrosion. At altitudes above 1000 meters, derate the output current per manufacturer guidelines. The robust Frame 6 construction supports long service life in demanding applications.
AC Drive for Industrial Demands
The Allen-Bradley PowerFlex 753 20F1ANC260JN0NNNNN is a robust AC drive engineered for reliable motor control in manufacturing and process industries. As part of the PowerFlex 753 series, this unit offers flexible performance with normal duty power of 132 kW and heavy duty power of 110 kW, making it suitable for a wide range of applications from conveyors to pumps.
Selection Guide and Purchasing Advice
When selecting this drive, verify your motor’s power requirements. For normal duty applications up to 132 kW, the 20F1ANC260JN0NNNNN provides ample headroom. For heavy duty cycles, the 110 kW rating ensures reliable operation. AutoDCSTech stocks this unit and can confirm current lifecycle status and availability before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 20F1ANC260JN0NNNNN |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
