Allen-Bradley 22D-E6P6H204 PowerFlex 40P AC Drive, 6.6 A, 5 HP

Technical Specifications Breakdown

Key parameters for the 22D-E6P6H204 are listed below for quick reference:

Industry Applications and Operational Benefits

The 22D-E6P6H204 provides a 3-phase output voltage range of 0 to 574V AC with 6.6A output current, supporting motors up to 4kW (5HP). Its 0.98 power factor across the entire speed range minimizes reactive power penalties, improving overall system efficiency. The integrated Class 10 electronic motor overload protection helps prevent motor burnout, reducing downtime and maintenance costs.

Installation and Setup Guidance

When installing the drive, ensure the input voltage matches the rated 460 to 600V AC range. The drive accepts ±10% line tolerance at 47 to 63Hz. Use the integral RS-485 port for programming and multi-drop network configurations. The open NEMA Type - Plate Mount (IP20) enclosure requires installation in a suitable cabinet to protect against dust and moisture. Verify that the ambient temperature does not exceed 40°C to maintain reliable operation.

Maintenance and Reliability Considerations

The 22D-E6P6H204 is designed for long service life with a drive efficiency of 97.5%. Periodic inspection of the enclosure and connections is recommended to ensure proper airflow and electrical integrity. The drive operates in a functional temperature range of 14 to 122°F with 5 to 95% non-condensing relative humidity. Its power ride-thru time of 100ms and 2s logic ride-thru help maintain operation during brief power disturbances, reducing nuisance trips.

PowerFlex 40P Drive for Reliable Motor Speed Control

This adjustable frequency drive is engineered for closed-loop applications and systems requiring a Category 3 safe-off function. Its zero-stacking feature saves valuable panel space while allowing operation at ambient temperatures up to 40°C. The drive is easily configured using an external HIM or the integral DSI communication port with PC-based tools like Drive Tools SP and Drive Explorer.

Compatibility and Integration

The drive supports Volt per Hertz and Sensorless Vector Control using a Sine Coded PWM signal with a carrier frequency range of 2 to 16 kHz. It includes 7 digital inputs (2 dedicated for start/stop, 5 programmable) with Source or Sink modes selectable via DIP switch. Two isolated analog inputs accept -10 to 10V or 4 to 20mA signals, and one non-isolated analog output provides 0 to 10V or 4 to 20mA. A single Form C relay output handles 3A resistive and 0.5A inductive loads at 125V AC. The integral RS-485 port enables PC programming and multi-drop networking.

Selection and Purchasing Advice

When selecting a drive for your application, consider the motor's power rating and the required control method. The 22D-E6P6H204 offers a programmable output frequency range of 0 to 500Hz, making it versatile for various speed requirements. Its compact dimensions of 125mm x 204mm x 97.5mm and weight of 1.6Kg simplify panel layout. For availability and lifecycle status, contact AutoDCSTech. They offer genuine Allen-Bradley parts with expert support to ensure you get the right component for your system.
