Allen-Bradley 22F-D6P0N113 PowerFlex 4M AC Drive 3 HP

PowerFlex 4M Adjustable Frequency AC Drive Overview

This PowerFlex 4M drive is engineered for simple machine-level speed control, offering a practical balance of performance and ease of use.

Technical Specifications Breakdown

Key parameters for the 22F-D6P0N113 are listed below for quick reference:

Built for Real-World Applications

The 22F-D6P0N113 is well-suited for applications that demand consistent speed regulation and simple integration. Typical uses include conveyor systems, fans, pumps, and other industrial machinery where a 3 HP (2.2 kW) motor is common. Its compact A-frame design and support for zero stacking at 40°C ambient temperature make it a flexible option for control panels with limited space.

Installation and Setup Guidance

Before installation, verify that the input voltage matches the drive's rating of 380-480 VAC, 3-Phase. Ensure the enclosure provides adequate ventilation and meets the IP20/NEMA open type requirements. The drive supports DIN rail or direct panel mounting, which simplifies retrofits. For initial setup, use the built-in fixed keypad with LCD display to configure parameters. The RS485 port allows for networked control using Modbus RTU or DSI protocols.

Maintenance and Reliability

Regular inspection of the drive's cooling fans and air filters (if used) is recommended to prevent overheating. Check all power and control wiring connections periodically to ensure they remain tight and free of corrosion. The built-in EMC filter helps suppress line noise, and the removable MOV protects against voltage transients, contributing to long-term reliability.

Compatibility and Integration

The 22F-D6P0N113 integrates easily into existing automation systems. The RS485 communication port supports Modbus RTU and DSI protocols, allowing connection to PLCs, HMIs, and other Allen-Bradley devices. For advanced networking, external DSI communication kits can add protocols like EtherNet/IP, DeviceNet, or PROFIBUS DP. The five discrete inputs and two analog inputs provide flexible control options.

Selection Guide and Purchasing Advice

When selecting a replacement or new drive, confirm that the voltage, current, and horsepower ratings match your motor and application. The 22F-D6P0N113 is a 3 HP, 2.2 kW drive with an output current of 6.0 A. At AutoDCSTech, we stock this model and offer competitive pricing. Contact us to verify current lifecycle status and availability before ordering.
