Technical Specifications Breakdown
Key parameters for the 20F11ND022JA0NNNNN are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F11ND022JA0NNNNN |
| Horsepower Rating | 15 horsepower |
| Output Power Rating | 11 kilowatts |
| Voltage Rating | 480 Volts AC and 650 Volts DC |
| Current Rating | 22 Amperes |
| Rated Phase | 3-phase |
| Frequency Tolerance | 47 to 63 Hertz |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Storage Temperature | -40 to 70°C (in a non-condensing environment) |
| Cooling Method | Air cooling |
| Braking Unit | Internal transistor included |
| Filtering | Filter included |
| Input Type | AC input with precharge and DC terminals |
| User Interface | No Human Interface Module (HIM) |
| Weight | 30.00 lbs (13.61 kg) |
Industry Applications Driving ROI
This AC drive is well-suited for conveyors, pumps, and fans where variable speed control reduces energy consumption. By matching motor speed to load demand, the PowerFlex 753 minimizes wasted power, directly lowering electricity bills. The internal braking transistor also recovers energy during deceleration, further improving system efficiency.
Installation and Setup Guidance
Mount the drive in a clean, dry location with adequate airflow for air cooling. Ensure the input voltage matches the 480 VAC / 650 VDC rating. The AC input with precharge simplifies startup, while the included common mode (CM) capacitor jumper reduces installation time. Because no Human Interface Module (HIM) is included, plan to use a remote interface or software for configuration.
Maintenance and Reliability
Periodically inspect the air cooling vents and filter to prevent dust buildup, which can reduce thermal performance. The drive operates reliably between 0 and 40°C ambient; storage between -40 and 70°C is acceptable. Regular checks of the internal braking transistor and connections help maintain long service life.
Cost-Efficient Motor Control with the Allen-Bradley 20F11ND022JA0NNNNN
When managing industrial motor applications, every specification impacts your operational costs. The Allen-Bradley PowerFlex 753 AC Drive, model 20F11ND022JA0NNNNN, is engineered to deliver reliable performance while keeping total cost of ownership in check. This 15 horsepower (11 kilowatt) drive operates on 480 volts AC and 650 volts DC, providing flexibility for diverse installations.
Compatibility and Integration
The filtered design suppresses electrical noise, making this drive compatible with sensitive automation networks. The 3-phase input and 47–63 Hz frequency tolerance align with standard industrial power systems. For seamless integration, consult the PowerFlex 753 documentation for communication options.
Selection Guide and Purchasing Advice
When selecting a drive, match the horsepower and current ratings to your motor nameplate. The 20F11ND022JA0NNNNN offers 22 amps at 480 VAC, suitable for many 15 HP applications. Please verify current lifecycle status and availability with AutoDCSTech before ordering. Our team can help confirm compatibility and advise on any additional accessories.
Availability & Condition at AutoDCSTech
| Part Number | 20F11ND022JA0NNNNN |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
