Product Overview
The 330103-00-04-05-02-05 is a 3300 XL 8 mm Proximity Probe from Bently Nevada, a trusted brand in machinery protection. It features an M10 x 1 thread, a 40 mm overall case length, and a 0.5 meter (1.6 feet) total length with a miniature coaxial ClickLoc connector and standard cable. The probe tip is made of polyphenylene sulfide (PPS), and the case is AISI 303 or 304 stainless steel (SST). It carries CSA, ATEX, and IECEx approvals for use in hazardous areas.
Technical Specifications Breakdown
Key parameters for the 330103-00-04-05-02-05 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 |
| Unthreaded Length | 00 mm |
| Overall Case Length | 40 mm |
| Total Length | 0.5 meter (1.6 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approvals | CSA, ATEX, IECEx |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Linear Range | 2 mm (80 mils), from 0.25 to 2.3 mm (10 to 90 mils) |
| Recommended Gap Setting (Radial Vibration) | -9 Vdc [approximately 1.27 mm (50 mils)] |
| Nominal Probe DC Resistance (0.5m) | 7.45 ± 0.50 Ω |
| Probe Temperature Range (Standard) | -52°C to +177°C (-62°F to +350°F) |
| Probe Weight | 323 g/m (11.4 oz) |
Industry Applications
Its 2 mm linear range and -9 Vdc recommended gap setting provide reliable data for predictive maintenance programs. The CSA/ATEX/IECEx approvals allow installation in Zone 0 and Zone 2 hazardous areas when paired with appropriate intrinsic safety barriers or non-incendive circuits.
Installation & Setup Guidance
Mount the probe with maximum thread engagement of 15 mm for the M10 x 1 thread. Use field wiring of 0.2 to 1.5 mm² (16 to 24 AWG) with a 3-conductor shielded triad cable. Maximum distance between the 3300 XL Proximitor Sensor and the monitor is 305 meters (1,000 feet). For radial vibration, set the gap to -9 Vdc (approximately 1.27 mm or 50 mils).
Maintenance & Reliability
Inspect the probe and cable periodically for physical damage. Avoid exposing the probe to temperatures below -34°C (-30°F) to prevent premature pressure seal failure. The probe is designed to seal differential pressure between tip and case using a Viton® O-ring. Contact AutoDCSTech for custom pressure testing requirements.
Compatibility & Integration
The 330103-00-04-05-02-05 works with Bently Nevada 3300 XL Proximitor Sensors and compatible monitoring systems. For intrinsically safe installations, use zener barriers per drawing 141092 or galvanic isolators. For non-incendive circuits, follow drawing 140979.
Selection Guide & Purchasing Advice
When selecting a proximity probe, confirm your required cable length, connector type, and agency approvals. The 330103-00-04-05-02-05 is a standard configuration with 0.5m cable and ClickLoc connector. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 330103-00-04-05-02-05 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
