Product Overview
When industrial connectivity demands robust and organized interfacing, the FANUC A02B-0072-C204 Connector Panel delivers a practical solution. This panel-mounted unit integrates seven standard 25-pin D-sub male connectors into a single, space-saving enclosure. Designed for panel installation, it provides a centralized point for connecting multiple devices or components in automation systems.
Technical Specifications
The A02B-0072-C204 from FANUC is built for reliable performance in controlled environments. Key specifications include:
- Manufacturer: FANUC
- Product Type: Connector Panel
- Part Number: A02B-0072-C204
- Weight: 1.25 lbs (0.57 kg)
- Mount Type: Panel Mounted
- Number of Connectors: 7
- Connector Type: Standard 25-pin D-sub Male Connectors
- Enclosure Rating: NEMA 1
- Cooling: Natural
- Maximum Ambient Temperature: 40 degrees Celsius
- Minimum Ambient Temperature: 0 degrees Celsius
- Maximum Operating Humidity: 80% (non-condensing)
- Maximum Storage Humidity: 80% (non-condensing)
- Maximum Operating Altitude: 1000 meters above sea level
These parameters ensure the panel operates reliably within typical industrial indoor environments. The NEMA 1 enclosure protects against dust and light contact, while natural cooling keeps the unit within safe temperature ranges without additional fans.
Industry Applications
This connector panel suits applications requiring multiple serial or parallel connections in a compact footprint. For example:
- CNC Machine Integration: Connect control signals between a FANUC CNC controller and peripheral devices like servo drives or I/O modules. The seven D-sub ports simplify wiring and reduce clutter.
- Automation Workcells: Use the panel as a central breakout point for sensors, actuators, and operator interfaces. Its panel mount design allows secure installation inside electrical cabinets.
- Test Equipment Racks: Organize signal connections for data acquisition or diagnostic tools. The standardized 25-pin connectors support common industrial communication protocols.
Installation & Setup Guidance
Mount the A02B-0072-C204 securely to a flat panel using appropriate hardware (not included). Ensure the mounting surface provides adequate support for the unit's weight. Route cables to the 25-pin D-sub connectors, verifying each connection is fully seated and locked with screws. Avoid bending cables sharply near the connectors to prevent strain. Operate the panel within the specified temperature range of 0°C to 40°C and maintain humidity below 80% non-condensing. For altitudes above 1000 meters, consult FANUC for derating guidelines.
Maintenance & Reliability
Routine maintenance for this connector panel is minimal. Periodically inspect the D-sub connectors for signs of wear, corrosion, or loose pins. Clean the enclosure exterior with a dry cloth; do not use solvents or abrasive materials. Verify that the NEMA 1 seal remains intact and that no dust buildup obstructs natural cooling. Given the passive design, the A02B-0072-C204 offers long service life with low maintenance requirements.
Frequently Asked Questions
Q1: What is the weight of the FANUC A02B-0072-C204?
The panel weighs 1.25 lbs (0.57 kg), making it lightweight for panel mounting.
Q2: How many connectors does the A02B-0072-C204 have?
It features seven standard 25-pin D-sub male connectors for versatile interfacing.
Q3: What is the operating temperature range?
The panel operates from 0°C to 40°C ambient temperature.
Q4: Is the enclosure rated for outdoor use?
No, the NEMA 1 rating is for indoor use only, providing protection against dust and light contact.
Q5: Does this panel require active cooling?
No, cooling is natural (passive). Ensure adequate airflow around the enclosure.
Selection Guide & Purchasing Advice
Before ordering the A02B-0072-C204, verify that your application requires seven 25-pin D-sub male connectors and panel mounting. Confirm compatibility with your existing cables and devices. SpareTechPLC stocks this FANUC connector panel and can provide current availability and lifecycle status. Contact our team for assistance with replacement or upgrade needs.
