Product Overview
When your industrial process demands precise motor speed control and reliable performance, the FANUC VFS15-2055PM-W1 AC drive delivers. This Toshiba Motors & Drives unit, part of the VF-S15 series, is a micro-drive variable frequency drive (VFD) designed for three-phase applications. It provides sinusoidal PWM control with a frequency range of 0.1 to 500.0 Hz, defaulting to 0.5 to 60 Hz, and supports maximum frequencies from 30 to 500 Hz. With a 7.5 HP rating and 27.5 full load amps at 230 VAC, this drive is built to handle demanding loads efficiently.
Technical Specifications Breakdown
- Horsepower and Current: The VFS15-2055PM-W1 is rated at 7.5 HP with 27.5 full load amps, ensuring robust power delivery for medium-duty motors.
- Supply Voltage: It operates on 230 VAC three-phase input, making it suitable for standard North American and global industrial power systems.
- Control Method: Sinusoidal PWM control provides smooth motor operation and reduced harmonic distortion, ideal for applications requiring consistent torque.
- Frequency Range: With a default setting of 0.5 to 60 Hz and an adjustable maximum from 30 to 500 Hz, this drive offers flexibility for both low-speed and high-speed processes.
- Built-in Features: The unit includes an operation panel for local control and a built-in basic filter to reduce electrical noise, enhancing reliability in sensitive environments.
Industry Applications
This AC drive excels in applications such as conveyor systems, pumps, fans, and compressors where variable speed control improves energy efficiency and process accuracy. For example, in a material handling line, the VFS15-2055PM-W1 can precisely adjust motor speed to match load demands, reducing wear and energy consumption. Its compact dimensions (17.0 cm x 15.0 cm x 22.0 cm) and light weight (3.5 kg) simplify integration into existing panels.
Installation and Setup Guidance
Mount the drive in a clean, dry location with adequate ventilation. Ensure the input power matches the 230 VAC three-phase supply. Connect the motor leads to the output terminals, observing proper phase rotation. Use the operation panel to configure basic parameters like frequency range and acceleration/deceleration times. Refer to the Toshiba VF-S15 manual for detailed wiring diagrams and parameter settings.
Maintenance and Reliability
Regular inspection of cooling fans and air filters is recommended to prevent overheating. Check terminal connections for tightness annually. The built-in basic filter reduces electromagnetic interference, prolonging the life of nearby sensitive equipment. Given its robust design, the VFS15-2055PM-W1 offers dependable service in continuous-duty applications.
Compatibility and Integration
This drive is compatible with standard three-phase induction motors up to 7.5 HP. It can be integrated with PLCs or other controllers via analog or digital inputs (refer to the manual for specific I/O configurations). The operation panel allows for standalone operation without external controllers.
Selection Guide and Purchasing Advice
Before purchasing, verify that your motor's full load amps do not exceed 27.5 amps and that your power supply is 230 VAC three-phase. The VFS15-2055PM-W1 is a world model with a built-in filter, suitable for global use. SpareTechPLC stocks this unit and can provide current availability and lifecycle status. Contact us to confirm stock and any replacement options if needed.
Frequently Asked Questions
Q: What is the full load amp rating of the VFS15-2055PM-W1?
A: The full load amp rating is 27.5 amps at 230 VAC.
Q: Does this drive include an operation panel?
A: Yes, the VFS15-2055PM-W1 comes with a built-in operation panel for local control.
Q: What is the frequency range of this AC drive?
A: The default frequency range is 0.5 to 60 Hz, with an adjustable maximum from 30 to 500 Hz.
Q: Is this drive suitable for single-phase input?
A: No, this model is designed for three-phase input only, as indicated by the "None" power phase code meaning three-phase.
Q: What does the "M" in the model number signify?
A: The "M" indicates a built-in basic filter for reduced electromagnetic interference.
