IC200ALG322: Output module
The IC200ALG322 is the Output module covered on this page. The attribute that decides whether it fits the existing installation without modification is 4 channels.
What separates this variant from its siblings is output module. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. output module sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 4 channels against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC200ALG322 |
| Series | Versamax |
| Part Number | IC200ALG322 |
| Type | Output module |
| Channels | 4 |
| Resolution | 12 bits |
| Isolation | 250VAC continuous |
| LED Indicators | 2 |
| Current Consumption | 160 mA max |
| Current Consumption at 12V | 210 mA max |
| Output Voltage | +/-10.24V DC |
| Load Resistive | 5000 Ohms |
| Channel-to-Channel Crosstalk Rejection | 70 dB minimum. |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-ic200alg320-4-point-analog-current-output-module-for-versamax | confirm the configuration against your installation |
| ge-fanuc-ic200alg325-versamax-analog-output-module-8-channel | confirm the configuration against your installation |
| ge-ic200alg321-versamax-4-point-analog-voltage-output-module | confirm the configuration against your installation |
| ge-ic200alg326-versamax-13-bit-analog-output-module-8-channels | confirm the configuration against your installation |
| ge-fanuc-ic200alg327-versamax-analog-output-module-8-channels | confirm the configuration against your installation |
| ge-ic200alg328-versamax-analog-output-module-for-industrial-automation | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC200ALG322 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
