What Is the KEB 09F5C1B-3A0A?
When your production line demands precise motor control and robust reliability, the KEB 09F5C1B-3A0A delivers. This frequency inverter belongs to the COMBIVERT F5 series and provides a power rating of 1.5 kW. It operates on a 3-phase 400 VAC supply and handles input current of 4.1 A with a maximum current of 8.9 A. The IP20 enclosure makes it suitable for controlled indoor environments. This drive is engineered for applications that require accurate speed and torque management.
Technical Specifications Breakdown
The 09F5C1B-3A0A includes several key parameters that define its performance. The switching frequency ranges from 8 to 16 kHz, allowing you to balance motor noise and efficiency. It supports multiple feedback types: resolver, incremental encoder, Sin/Cos encoder, and absolute encoder. This flexibility ensures precise motor monitoring and control. The drive also features short-circuit monitoring and earth fault monitoring to enhance operational safety. It complies with EN 61800-2 and EN 61800-5-1 for product standards, and EN 61800-3 for emitted interference. The operating temperature range is –10 to 45 °C, while storage temperature extends from –25 to 70 °C.
Industry Applications
Manufacturing facilities often use the 09F5C1B-3A0A in conveyor systems, pumps, and fans. Its 1.5 kW power rating suits medium-duty applications. The encoder feedback options make it ideal for positioning tasks in packaging or material handling. The drive's short-circuit and earth fault monitoring reduce unplanned downtime, protecting both the equipment and the process. For example, in a bottling line, the drive maintains consistent conveyor speed while the monitoring features alert operators to ground faults before they cause a shutdown.
Installation & Setup Guidance
Mount the KEB 09F5C1B-3A0A in a clean, dry cabinet with adequate ventilation. Ensure the ambient temperature stays within –10 to 45 °C. Use shielded cables for encoder and serial interfaces to minimize electromagnetic interference. The potential-free operator connection allows remote control integration. Verify that the 3-phase 400 VAC supply matches the input specifications. Follow the wiring diagram provided in the manual to connect the motor and feedback devices correctly.
Maintenance & Reliability
Regular inspection of the drive's cooling fan and air filters extends its service life. Check for dust accumulation on the IP20 enclosure vents. Monitor the operating temperature to stay within the specified range. The drive's built-in short-circuit and earth fault monitoring help detect issues early. By following a routine maintenance schedule, you reduce the risk of unexpected failures and maximize the return on your investment.
Compatibility & Integration
The 09F5C1B-3A0A integrates with various motor types and feedback devices. It supports resolver, incremental encoder, Sin/Cos encoder, and absolute encoder feedback. Serial interfaces are available for communication with higher-level control systems. The potential-free operator connection enables simple start/stop and speed reference control. This drive works well with KEB's COMBIVERT family and other automation components.
Selection Guide & Purchasing Advice
Before purchasing the KEB 09F5C1B-3A0A, confirm your motor's power rating and feedback requirements. Verify that your supply voltage is 3-phase 400 VAC. Check the enclosure space for the drive's dimensions: 22 cm height, 9 cm width, and 16 cm length. The weight is 2 kg. SpareTechPLC stocks this model and can assist with availability and technical questions. Contact us to confirm lifecycle status and ensure the drive meets your application needs.
Frequently Asked Questions
Q: What is the maximum output frequency of the 09F5C1B-3A0A?
A: The output frequency range is 0-800 Hz, as specified in the full description.
Q: Does this drive support absolute encoder feedback?
A: Yes, the 09F5C1B-3A0A supports absolute encoder feedback, along with resolver, incremental encoder, and Sin/Cos encoder.
Q: What is the IP rating of the KEB 09F5C1B-3A0A?
A: The enclosure type is IP20, suitable for indoor, controlled environments.
Q: Can I use this drive with a single-phase supply?
A: No, the 09F5C1B-3A0A requires a 3-phase 400 VAC input. It is not designed for single-phase operation.
Q: What safety features does this drive include?
A: It includes short-circuit monitoring and earth fault monitoring to enhance operational safety.
