Product Overview
When small-scale automation demands reliable control, the Mitsubishi FX3SA-14MT-CM third generation micro programmable controller delivers. This compact PLC from Mitsubishi Electric offers 14 input and output points, making it a perfect fit for applications where space is limited but performance cannot be compromised. With an AC100-240V power supply and transistor output (drain), the FX3SA-14MT-CM handles basic control tasks efficiently.
Technical Specifications Breakdown
The FX3SA-14MT-CM provides 8 input points and 6 output points, all in a transistor output (drain) configuration. Power consumption is just 19W, and the unit weighs only 0.3 kg. Its outline dimensions of 60x90x75 mm allow installation in tight panels. The PLC operates on AC100-240V, making it compatible with standard industrial power supplies worldwide.
Industry Applications
This controller excels in small-scale equipment requiring basic logic control, such as packaging machines, conveyor systems, and simple assembly lines. Its compact size and low power consumption make it ideal for standalone machines or as a remote I/O node in larger systems. The transistor output provides fast switching for high-speed applications like labeling or sorting.
Installation & Setup Guidance
Mount the FX3SA-14MT-CM on a DIN rail or directly to a panel using the provided mounting holes. Ensure the ambient temperature stays within the operating range (not specified, but typical for similar units). Connect the AC power supply to the designated terminals, and wire inputs according to the sink/source configuration. Use shielded cables for communication lines to minimize noise.
Maintenance & Reliability
Routine inspection of the power supply and I/O connections ensures long-term reliability. The solid-state transistor outputs have no moving parts, reducing wear. Keep the enclosure clean and free of dust. The FX3SA-14MT-CM is designed for continuous operation in industrial environments, with a robust construction that withstands vibration and temperature variations.
Compatibility & Integration
The FX3SA-14MT-CM is part of the Mitsubishi FX3S series, compatible with expansion modules and special adapters. It supports MODBUS and Ethernet communication when paired with appropriate modules, enabling integration into larger networks. The controller can also interface with Mitsubishi HMIs and drives for comprehensive system control.
Selection Guide & Purchasing Advice
Before purchasing, verify that the I/O count and output type match your application. The FX3SA-14MT-CM is a transistor drain output model, suitable for DC loads. For AC loads, consider a relay output version. SpareTechPLC offers this model with fast shipping and expert support to ensure you get the right part for your system.
Frequently Asked Questions
Q: What is the power supply requirement for the FX3SA-14MT-CM?
A: It requires AC100-240V, single-phase.
Q: How many input and output points does it have?
A: It has 8 input points and 6 output points, totaling 14 I/O.
Q: What type of output does the FX3SA-14MT-CM use?
A: It uses transistor output (drain), suitable for DC loads.
Q: Can this PLC communicate over Ethernet?
A: Yes, with optional expansion modules, it supports MODBUS and Ethernet communication.
Q: What is the weight and size of this controller?
A: It weighs 0.3 kg and measures 60x90x75 mm.
