What Is the Mitsubishi GT2708-VTBD?
When your production line demands a robust and reliable human-machine interface, the Mitsubishi GT2708-VTBD delivers. This GT27 model from the GOT2000 series provides a clear 8.4-inch TFT display with 65536 colors and VGA resolution (640x480 pixels). It operates on 24 VDC power and includes touch, pinch, and zoom functionality for intuitive operator interaction. The black enclosure meets IP67F protection standards, making it suitable for harsh industrial environments.
Technical Specifications Breakdown
The GT2708-VTBD offers 128 MB of internal memory and supports SD memory cards for data storage and transfer. Connectivity includes one Ethernet port, one RS-232 port, one RS-422/485 port, and three USB ports. It also features a slot for optional cards, allowing network expansion via MODBUS, PROFIBUS, MELSECNET, ETHERNET, or CCLINK. The unit measures 241 mm wide, 194 mm high, and 52 mm deep, with a weight of 1.5 kg.
Industry Applications
This HMI excels in manufacturing environments where operators need real-time data visualization and control. For example, in a packaging line, the GT2708-VTBD can display machine status, alarm logs, and production counts. Its IP67F protection resists dust and water ingress, ideal for washdown areas. The multiple communication ports enable seamless integration with PLCs and drives from various brands.
Installation & Setup Guidance
Mount the GT2708-VTBD securely in a panel cutout using the provided gaskets to maintain its IP67F rating. Connect 24 VDC power to the designated terminals, observing polarity. Use the RS-232 or Ethernet port for initial configuration via GOT2000 software. Ensure all cable connections are tight to prevent signal loss. The SD card slot allows easy firmware updates and recipe transfers.
Maintenance & Reliability
Regularly inspect the display surface for scratches or cracks that could compromise touch sensitivity. Clean the screen with a soft, dry cloth. Verify that all cable connectors remain secure. The IP67F protection means the unit can withstand occasional water jets, but avoid prolonged submersion. Check the memory card slot for dust buildup. Following these steps extends the HMI's service life and reduces unplanned downtime.
Compatibility & Integration
The GT2708-VTBD integrates with Mitsubishi PLCs and drives via MELSECNET or CCLINK networks. It also supports MODBUS and PROFIBUS for third-party devices. The Ethernet port enables remote monitoring and data logging. Use the USB ports for mouse, keyboard, or barcode scanner connectivity. The optional card slot adds flexibility for specialized network requirements.
Selection Guide & Purchasing Advice
Before ordering, confirm that your system requires a GT27 model with 8.4-inch display and 24 VDC power. Verify the network protocol needed—MODBUS, PROFIBUS, or others—and ensure the optional card is included if necessary. SpareTechPLC stocks the GT2708-VTBD and can advise on compatible accessories. Check the current lifecycle status with our team to ensure long-term support.
Please verify current lifecycle status and availability with SpareTechPLC before ordering.
