Product Overview
This GT27 MODEL human machine interface from the GOT2000 SERIES provides a 12.1-inch TFT display with 65536 colors and 800x600 pixel resolution. The GT2712-STBA handles demanding industrial environments with an IP67F protection class, making it suitable for washdown and dusty areas. Its AC power supply accepts 100-240 VAC, simplifying integration into global installations.
Technical Specifications Breakdown
The GT2712-STBA offers key specifications that matter for industrial applications:
- Display: 12.1-inch TFT with 65536 colors and 800x600 resolution ensures clear, detailed graphics for process monitoring.
- Memory: 256 MB internal memory capacity provides ample space for screen data and application storage.
- Connectivity: One Ethernet port, one RS-232, one RS-422/485, and three USB ports enable flexible communication with controllers and peripherals.
- Expansion: An SD memory card slot and a slot for optional cards allow easy data logging and function upgrades.
- Network Options: Supports CCLINK, PROFIBUS, ETHERNET, MELSECNET, and MODBUS protocols for integration into diverse automation architectures.
Industry Applications
In manufacturing environments, the GT2712-STBA as a central HMI for machine control and monitoring. For example, in a packaging line, its 12.1-inch display shows real-time production metrics, while the RS-422/485 port connects to variable frequency drives. The IP67F rating allows installation near washdown stations without enclosure modifications. In automotive assembly, the Ethernet port links to a PLC network for coordinated cell control, and the SD card slot stores recipe data for quick changeovers.
Installation & Setup Guidance
Mount the GT2712-STBA in a panel cutout using the provided gaskets to maintain its IP67F seal. Connect the AC power supply (100-240 VAC) to the dedicated terminals, ensuring proper grounding. Use the RS-232 or RS-422/485 port for initial configuration with Mitsubishi GOT2000 software. The Ethernet port supports network-based setup and data transfer. Verify that the SD card is inserted before power-up if using data logging functions.
Maintenance & Reliability
The GT2712-STBA requires minimal routine maintenance. Inspect the front panel seal periodically to ensure IP67F integrity, especially in wet or dusty environments. Clean the TFT screen with a soft, dry cloth when needed. The 256 MB internal memory retains application data without battery backup, reducing long-term service needs. For maximum uptime, keep the firmware updated via the Ethernet port and monitor the SD card for available space.
Compatibility & Integration
The built-in Ethernet port supports MELSECNET and MODBUS TCP/IP communication. The RS-232 and RS-422/485 ports connect to legacy devices, while the USB ports allow connection to barcode scanners or printers. Optional card slots expand functionality with additional communication modules. The GT2712-STBA works with CCLINK and PROFIBUS networks through the optional slot, making it a versatile choice for mixed-vendor systems.
Selection Guide & Purchasing Advice
Before ordering the GT2712-STBA, verify your system voltage (100-240 VAC) and available panel cutout dimensions. Confirm that the required network protocol (CCLINK, PROFIBUS, ETHERNET, MELSECNET, or MODBUS) is supported either natively or via optional card. AutoDCSTech stocks this model and can advise on compatible accessories such as SD cards, communication cables, and mounting brackets. Contact our team to confirm availability and lead times for your project.
Availability & Condition at AutoDCSTech
| Part Number | GT2712-STBA |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Japan |
