What Is the Mitsubishi HG-MR053?
When your automation system demands precise motion control in a compact footprint, the Mitsubishi HG-MR053 delivers. This AC servo motor from the HG Series is engineered for small power capacity applications. It provides reliable performance with a rated speed of 3000 RPM and can reach a maximum speed of 6000 RPM for tasks requiring rapid acceleration.
Performance Specifications Breakdown
The HG-MR053 offers a rated torque of 0.16 Nm and a maximum torque of 0.48 Nm. This torque range suits light to moderate load handling. The rated current is 1 Amp, with a maximum current of 3.1 Amps, ensuring robust operation under peak demands. Its rated output is 0.05 kW, making it ideal for precision positioning in small machinery.
The motor operates within a temperature range of 0 to 40 degrees Celsius and can be stored between -15 to 70 degrees Celsius. This flexibility allows integration into various industrial environments without performance degradation.
Real-World Applications
In pick-and-place systems, the HG-MR053’s 22-bit absolute encoder provides high positioning accuracy, reducing errors in repetitive tasks. For labeling or small assembly machines, its IP65 rating protects against dust and water splashes, ensuring reliability in production floors. The standard straight shaft simplifies coupling to loads, while the 4-pin rectangular connector offers secure power and signal connections.
Installation and Setup Guidance
Mount the HG-MR053 securely using its standard straight shaft. Ensure the operating environment stays within 0 to 40 degrees Celsius. Connect the 4-pin rectangular connector to the compatible servo drive. Verify the encoder wiring for the 22-bit absolute encoder to maintain positioning integrity. Always follow the manufacturer’s guidelines for torque specifications on mounting bolts.
Maintenance and Reliability
Regularly inspect the motor for dust accumulation on the shaft and connector. The IP65 rating reduces maintenance frequency, but periodic checks of the cable and connector integrity are recommended. Store the motor in temperatures between -15 to 70 degrees Celsius when not in use. Avoid exposing the motor to excessive vibration or shock to prolong service life.
Compatibility and Integration
The HG-MR053 integrates with Mitsubishi servo drives that support 22-bit absolute encoder feedback. It is compatible with motion controllers used in small-scale automation systems. The 4-pin rectangular connector standardizes wiring, simplifying replacement or system upgrades.
Selection Guide and Purchasing Advice
Before ordering, confirm that your application requires a small power capacity motor with 0.05 kW output. Verify that the servo drive supports the 22-bit absolute encoder. For current availability and lifecycle status, contact SpareTechPLC. We stock genuine Mitsubishi parts and can assist with replacement options if needed.
Frequently Asked Questions
What is the maximum speed of the HG-MR053?
The maximum speed is 6000 RPM, while the rated speed is 3000 RPM.
What encoder type does this motor use?
It uses a 22-bit absolute encoder for precise position feedback.
Is the HG-MR053 suitable for dusty environments?
Yes, its IP65 rating protects against dust ingress and water splashes.
What is the rated output power?
The rated output is 0.05 kW.
What connector type does the motor have?
It features a 4-pin rectangular connector.
