What Is the HG-MR23 Servo Motor?
When your automated assembly line demands precise positioning and reliable torque, the Mitsubishi HG-MR23 delivers. This servo motor, part of the HG / MELSERVO-J4 series, is engineered for rigorous motion control tasks. With a rated capacity of 0,2 kW and a rated torque of 0,64 Nm, it provides consistent power for applications requiring both finesse and force. Its maximum torque of 1,9 Nm handles peak loads without hesitation.
Technical Specifications Breakdown
The HG-MR23 operates at a rated speed of 3000 RPM and can surge to a maximum speed of 6000 RPM, making it suitable for swift, accurate movements. It features a straight shaft type, simplifying coupling and ensuring balanced motion. The motor integrates an absolute/incremental encoder for precise positional feedback, enhancing system accuracy. With a protection class of IP65, it resists dust ingress and water jets, ideal for harsh environments. Dimensions are 60 x 77.1 x 76.6 mm, and it weighs 3.00 lbs (1.36 kg).
Industry Applications
In robotics, the HG-MR23 enables smooth, repeatable joint movements thanks to its high-speed capabilities and encoder feedback. For manufacturing machinery, its IP65 rating allows reliable operation in dusty or wet conditions. Automated assembly lines benefit from the motor's compact size and torque range, fitting tight spaces while delivering necessary force.
Installation & Setup Guidance
When mounting the HG-MR23, ensure the straight shaft aligns properly with the load to minimize vibration. Use appropriate couplings rated for 3000 RPM continuous operation. Verify the power supply matches 200 Volts AC. Connect the encoder cable carefully to maintain signal integrity for absolute/incremental feedback.
Maintenance & Reliability
Periodically inspect the motor for dust buildup on the IP65-sealed housing. Check shaft seals for wear in high-cycle applications. The motor's robust design reduces downtime, but regular verification of encoder alignment ensures long-term precision. Follow manufacturer guidelines for lubrication intervals.
Buying Guide
Before purchasing the HG-MR23, confirm your system's voltage and torque requirements match the 200 Volts AC supply and 0,64 Nm rated torque. Verify compatibility with your controller and drive. SpareTechPLC offers this model with fast shipping and expert support to help you select the right servo motor for your application.
Frequently Asked Questions
Q: What is the rated capacity of the HG-MR23?
A: The rated capacity is 0,2 kW.
Q: Does the HG-MR23 include a brake?
A: No, the HG-MR23 does not have a brake.
Q: What encoder type does the HG-MR23 use?
A: It uses an absolute/incremental encoder.
Q: What is the protection class of this servo motor?
A: The protection class is IP65.
Q: What is the maximum speed of the HG-MR23?
A: The maximum speed is 6000 RPM.
