Product Overview
When you need precise analog control in a compact package, the Schneider TSXASY410 delivers. This analog output module is part of the TSX Micro PLCs series and provides four channels of voltage or current output. It is designed for industrial automation tasks that require reliable signal generation.
Technical Specifications Breakdown
The TSXASY410 offers key specifications that matter for real-world performance:
- Output Type: Voltage or current, selectable per application needs.
- Number of Channels: 4 analog output channels.
- Voltage Output Range: 0 to 10 V.
- Current Output Range: 0 to 20 mA.
- Resolution: 12-bit resolution for fine control.
- Accuracy: ±0.2% of full scale ensures measurement reliability.
- Response Time: 1 ms per channel, suitable for applications requiring immediate feedback.
- Power Supply: 24 V DC with low power consumption of 3 W.
- Operating Temperature: 0 to 60°C, with storage from -40 to 85°C.
- Humidity: 5 to 95% non-condensing.
Industry Applications
In process control systems, the TSXASY410 provides precise analog signals to valves, actuators, and drives. For example, in a chemical plant, the module can output 4-20 mA signals to control flow valves. In manufacturing, its 0-10 V output can regulate variable frequency drives. The module's fast 1 ms response time makes it ideal for applications that need quick adjustments.
Installation & Setup Guidance
Mount the TSXASY410 in a standard TSX Micro PLC rack. Use the screw terminal block for electrical connections. Ensure the power supply is 24 V DC. For voltage output, maintain a minimum load impedance of 2 kΩ. For current output, keep the load impedance at 500 Ω or less. Follow the terminal descriptions for correct wiring.
Maintenance & Reliability
The TSXASY410 is built for durability with an IP20 protection degree. It operates reliably in temperatures from 0 to 60°C and humidity up to 95%. Regular inspection of connections and environmental conditions helps ensure long service life. The module includes overload and short-circuit protection for added safety.
Compatibility & Integration
This module integrates seamlessly with the TSX Micro PLCs series. It is part of the Modicon Premium automation platform. The module uses a standard format and connects via a screw terminal block. It is compatible with various Schneider PLC systems.
Selection Guide & Purchasing Advice
Before purchasing the TSXASY410, verify your PLC system compatibility. The module requires a 24 V DC power supply. Check the load impedance requirements for your output type. SpareTechPLC offers this module with fast shipping and reliable support. Contact us for current availability and pricing.
Frequently Asked Questions
What is the output range of the TSXASY410?
The module provides voltage output from 0 to 10 V and current output from 0 to 20 mA.
How many channels does the TSXASY410 have?
It has 4 analog output channels.
What is the response time of the TSXASY410?
The response time is 1 ms per channel.
What power supply does the TSXASY410 need?
It requires a 24 V DC power supply.
Is the TSXASY410 compatible with other Schneider PLCs?
It is designed for TSX Micro PLCs and the Modicon Premium platform.
