Why the 8LSA56.ee030ffgg-4 Excels in High-Dynamics Applications
In modern manufacturing, the demand for precise motion control continues to grow. Engineers need servo motors that deliver both high dynamics and positioning accuracy. The B&R 8LSA56.ee030ffgg-4 is a three-phase synchronous servo motor designed to meet these challenges. It features a permanent-magnet, electronically commutated design that supports demanding automation tasks.
This motor is part of the 8LSA series, known for its slim and elongated construction. The self-cooled design simplifies installation and reduces maintenance. With a nominal speed of 3000 rpm and a maximum speed of 5000 rpm, it offers flexibility across various production speeds. The motor's compact size and reduced weight make it suitable for applications where space is limited.
Key Technical Specifications of the 8LSA56.ee030ffgg-4
The 8LSA56.ee030ffgg-4 delivers robust performance metrics. Its nominal torque is 17.8 Nm, with a stall torque of 25.0 Nm. For peak demands, it can provide a maximum torque of 75.0 Nm. This high overload capacity ensures reliable operation during sudden load changes.
The motor operates with a nominal current of 10.9 A and a stall current of 15.3 A. Its maximum current reaches 64.6 A, enabling rapid acceleration and deceleration. The torque constant is 1.63 Nm/A, and the voltage constant is 98.44 V/1000rpm. These values indicate efficient torque generation per unit of current.
Additional electrical parameters include a stator resistance of 0.398 Ohm and a stator inductance of 5.6 mH. The electrical time constant is 14.1 ms, while the thermal time constant is 43 minutes. The motor's moment of inertia is 17.9 kg·cm², and its mass is 14.50 kg without brake. These characteristics contribute to precise control and stable performance.
Built-in Feedback and Safety Features
The 8LSA56.ee030ffgg-4 includes an embedded parameter chip for automatic drive identification. This simplifies setup and ensures optimal performance with compatible drives. The motor supports resolver or EnDat encoders, including inductive and optical types. Single-turn and multi-turn options are available, with 32-line resolution.
For functional safety, encoders are available that support safety-related position measurement. This allows integration into safety systems when paired with appropriate drives. The motor's thermal protection uses KTY83-110 (up to rev C7) or AM-PTC1000 (rev C8/C9). The maximum winding temperature is 155°C, but ACOPOS drives limit it to 110°C with EnDat and 130°C with resolver.
Compatibility with ACOPOS Servo Drives
The 8LSA56.ee030ffgg-4 is recommended for use with ACOPOS servo drives, specifically the 017X series. This pairing ensures optimal performance and reliable operation. The motor's parameter chip enables automatic drive identification, reducing commissioning time. The ACOPOS drive also implements STO (Safe Torque Off) for safety functions.
Integration is straightforward with the built-in plug-in connectors, including swivel and SpeedTec types. A single-cable hybrid solution is available, simplifying wiring. The motor's connectors support the speedtec (923) and itec/ytec/htec (723) systems, offering flexibility in connection options.
Application Scenarios for the 8LSA56.ee030ffgg-4
This servo motor is ideal for applications requiring high dynamics and precision. In packaging machinery, it can handle rapid indexing and precise positioning. The high overload capacity ensures smooth operation even with variable loads.
In material handling systems, the motor's compact design and high torque density are advantageous. It can drive conveyors or robotic arms with accuracy. The motor's IP64 protection rating (IP65 with optional oil seal) makes it suitable for dusty or wet environments.
For machine tools, the 8LSA56.ee030ffgg-4 provides the necessary speed and torque for cutting operations. Its low cogging and optimized torque ripple contribute to excellent surface finish. The motor's vibration severity A1 per EN 60034-14 ensures stable operation.
Comparison with Other Servo Motor Options
Compared to standard asynchronous motors, the 8LSA56.ee030ffgg-4 offers higher dynamics and better positioning accuracy. Its permanent-magnet design eliminates rotor losses, improving efficiency. The motor's compact size and reduced weight simplify machine design.
Within the 8LSA series, the -4 generation brings updates such as a center hole DIN 332 Form D and no eye bolts. The elevation limit is 2000 m with speedtec connectors or 4000 m with ytec connectors. These features enhance versatility in different installation scenarios.
Frequently Asked Questions
What is the nominal speed of the 8LSA56.ee030ffgg-4?
The nominal speed is 3000 rpm, with a maximum speed of 5000 rpm. This range allows for flexible operation across various applications.
What type of feedback does the motor support?
The motor supports resolver or EnDat encoders, including inductive and optical types. Single-turn and multi-turn options are available, with 32-line resolution.
Is the motor suitable for safety-related applications?
Yes, encoders for functional safety are available. The motor supports safety-related position measurement when paired with compatible drives like ACOPOS.
What is the recommended servo drive for this motor?
The recommended servo drive is the ACOPOS series, specifically the 017X model. This ensures optimal performance and automatic drive identification.
