Introduction to the Siemens 6XV1875-5AH20 Antenna Connection Cable
When signal integrity matters, the 6XV1875-5AH20 from Siemens delivers a reliable link between your antenna and SCALANCE M/W devices. This pre-assembled N-Connect male/male cable is engineered for IWLAN and mobile radio applications, offering a flexible 2-meter length that simplifies routing in tight spaces. With a transmission frequency range of 0 to 6000 MHz, it supports a wide array of industrial wireless setups.
Because it comes pre-assembled, installation is straightforward, reducing downtime and labor costs. The cable's robust construction, including a braided shield of tin-plated copper wires, ensures consistent performance in demanding environments. For engineers seeking a dependable connection solution, the 6XV1875-5AH20 is a practical choice.
Key Features and Technical Specifications
The 6XV1875-5AH20 is designed with performance and durability in mind. Its key specifications include:
- Length: 2 m flexible cable
- Connectors: N-Connect male/male (2 electrical connections)
- Frequency Range: 0 to 6000 MHz
- Impedance: 50 Ω rated
- Attenuation: 0.53 dB/m at 2.4 GHz, 0.83 dB/m at 5.2 GHz, 0.89 dB/m at 5.85 GHz
- Return Loss: Minimum 23 dB
- Capacitance: 82 pF/m at 1 kHz
- Relative Speed: 82%
- Outer Diameter: 6.3 mm (cable sheath)
- Bending Radius: 32 mm (single bend), 45 mm (multiple bends)
- Temperature Range: -40 to +80 °C (operation, storage, transport); -25 to +80 °C (installation)
- Protection Class: IP68 (when plugged in)
- Halogen-free and silicon-free
These specs translate into low signal loss and high reliability, which directly reduces maintenance costs and improves system uptime. The IP68 rating ensures protection against dust and water ingress, extending the cable's service life in harsh industrial settings.
Industry Applications and Use Cases
The 6XV1875-5AH20It is suitable for IWLAN and mobile radio systems, making it a versatile component in factory automation, logistics, and process control. For example, in a warehouse where wireless connectivity is critical for real-time inventory tracking, this cable ensures a stable link between access points and antennas, minimizing data dropouts.
Moreover, its wide frequency range supports both 2.4 GHz and 5 GHz bands, accommodating various wireless protocols. The flexible design allows for easy routing around corners and through cable trays, reducing installation time and associated labor costs.
Installation and Setup
Installing the 6XV1875-5AH20 is straightforward thanks to its pre-assembled N-Connect connectors. Simply plug one end into your antenna and the other into your SCALANCE M/W device. Ensure the connectors are tightened securely to maintain the IP68 rating and optimal signal integrity.
When routing the cable, respect the minimum bending radius of 32 mm for single bends and 45 mm for multiple bends to prevent damage to the inner conductor. Avoid exceeding the maximum tensile load of 80 N during installation. These precautions help preserve the cable's electrical performance and mechanical durability.
Maintenance and Reliability
To ensure long-term reliability, periodically inspect the cable for signs of wear, especially at connection points. Check that the connectors remain clean and free from corrosion. The cable's FRNC sheath offers flame resistance and is halogen-free, contributing to safety in fire-prone areas.
Given its temperature range of -40 to +80 °C, the 6XV1875-5AH20 can operate in extreme conditions, reducing the need for frequent replacements. This durability translates into lower total cost of ownership, as fewer maintenance interventions are required.
Compatibility and Integration
The 6XV1875-5AH20 is designed for use with Siemens SIMATIC NET antennas and SCALANCE M/W devices. It is also suitable for RCoax cable connections, making it a flexible solution for various industrial wireless architectures. The N-Connect interface is a standard in the industry, ensuring broad compatibility with other equipment.
Troubleshooting and Common Issues
Common issues with antenna cables include signal loss and connector failure. The 6XV1875-5AH20 mitigates these with its low attenuation values and robust construction. If you experience signal degradation, first check that both connectors are properly seated and tightened. Also, verify that the cable is not bent beyond its minimum radius, as this can cause internal damage.
If the cable is exposed to moisture, the IP68 rating provides protection, but it is still wise to inspect the connectors for any signs of water ingress. In case of persistent issues, consult the official Siemens documentation or contact AutoDCSTech for support.
Product Support and Availability
The 6XV1875-5AH20 is available through AutoDCSTech. As an industrial automation parts supplier, we ensure genuine Siemens products are in stock and ready to ship. For assistance with your order or technical questions, contact our team.
Availability & Condition at AutoDCSTech
| Part Number | 6XV1875-5AH20 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Germany |
