560PSU02: Power Supply Unit for RTU560 Subracks
The 560PSU02 is the Power Supply Unit for RTU560 Subracks covered on this page. The attribute that decides whether it fits the existing installation without modification is 48...220 V DC.
What separates this variant from its siblings is power supply unit for rtu560 subracks. A power supply or battery in a controller rack is sized against the backplane budget, not in isolation. power supply unit for rtu560 subracks is whether the unit delivers the voltage and current the rack draws at full load, and whether the battery holds programme and configuration through a power loss. Checking 48...220 V DC against the rack's requirement prevents a supply that fits the slot but cannot hold the load.
| Feature | Specification |
|---|---|
| Manufacturer | ABB |
| Brand | ABB |
| Part Number | 560PSU02 |
| Input Voltage | 48...220 V DC |
| Input Tolerance | -20%...+15% |
| Total Output Power | 85W |
| Output U1 | 5.1 V DC (5.0...5.3 V DC), 0A min, 15A max |
| Output U2 | 24 V DC (22.4...26.3 V DC), 0A min, 0.4A max |
| Efficiency | 74% @ 48...110 V DC |
| Dimensions | 160 mm x 100 mm, 3HE euro card format, 8R (40 mm) front panel |
| Weight | ca. 0.65 kg |
| Operating Temperature | 0°C...70°C |
| Relative Humidity | 5...95% (non-condensing). |
