Product Overview
When a reliable Modbus TCP connection is critical for your industrial network, the ABB CI867K01 Modbus TCP Interface delivers seamless communication. This Communication_Module integrates into ABB automation systems, providing a robust interface for data exchange. The package includes the CI867A Communication Interface and the TP867 Baseplate, ensuring a complete solution for your setup.
Technical Specifications
The ABB CI867K01 features a compact design with a product net depth of 127.5 mm, height of 186 mm, and width of 59 mm. Weighing only 0.7 kg, it fits easily into control cabinets. The product ID is 3BSE043660R1, and the ABB type designation is CI867AK01. It complies with RoHS status following EU Directive 2011/65/EU and falls under WEEE Category 5 for small equipment.
Industry Applications
In manufacturing environments, the CI867K01 enables real-time data exchange between PLCs and supervisory systems. For example, in a water treatment plant, it connects remote I/O devices to the central controller over Modbus TCP, improving process visibility. Its compact dimensions make it ideal for space-constrained panels.
Installation & Setup Guidance
Mount the TP867 baseplate securely in your cabinet using standard DIN rail or screw mounting. Attach the CI867A communication interface to the baseplate, ensuring proper alignment. Connect the Modbus TCP cable to the RJ45 port. Verify all connections before powering up the system.
Maintenance & Reliability
Regularly inspect the module for dust accumulation and ensure proper ventilation. The RoHS-compliant design supports environmental sustainability. With no batteries to replace, maintenance is minimal. Periodic checks of network connections help maintain reliable operation.
Compatibility & Integration
The CI867K01 integrates with ABB AC800M and other controllers supporting Modbus TCP. It works with standard Ethernet networks and requires no special software for basic setup. Ensure your network infrastructure supports Modbus TCP protocol.
Selection Guide & Purchasing Advice
Before purchasing the CI867K01, verify compatibility with your existing ABB system. Confirm that your controller supports Modbus TCP communication. SpareTechPLC offers this module with fast shipping and expert support. Contact us for current availability and pricing.
Troubleshooting & Common Issues
If the module fails to communicate, check the Ethernet cable and switch connections. Verify that the IP address settings match your network configuration. Ensure the TP867 baseplate is properly seated. For persistent issues, consult the ABB documentation.
