Technical Specifications Breakdown
Key parameters for the 150-F317NBRB are listed below for quick reference:
| Feature | Specification |
|---|---|
| Brand | Allen-Bradley |
| Product Type | Motor Controller |
| Number of Phases | 3 |
| Control Function | Motion |
| Supply Voltage | 100/240 V ac |
| Output Voltage | 460 V ac |
| Current Rating | 317 A |
| Power Rating | 250 HP |
| IP Rating | IP2X |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | EN/IEC 60947-1, CCC, UL 508, cULus Listed, CSA, CE, EN/IEC 60947-4-2 |
Reliable Motion Control for High-Power Industrial Applications
Industrial motor controllers must deliver consistent performance under demanding conditions. The Allen-Bradley 150-F317NBRB provides robust control for high-horsepower applications, combining a 250 HP rating with a 317 A current capacity. This 3-phase unit operates on a 100/240 V AC supply and outputs 460 V AC, making it suitable for a wide range of heavy machinery.
Industry Applications for High-Current Motor Control
Typical applications include conveyor systems in mining and aggregate processing, where the 317 A rating supports heavy belt loads. It also suits large pumps in water treatment facilities and industrial compressors. The IP2X enclosure provides basic protection against solid objects, making it appropriate for indoor industrial settings.
Installation and Setup Guidance
When installing the 150-F317NBRB, ensure the supply voltage matches the 100/240 V AC rating and the output connects to a 460 V AC motor. Verify that the ambient temperature stays within -5°C to 50°C. Mount the controller in a clean, dry location to maintain the IP2X protection. Always follow local electrical codes and the manufacturer's wiring diagrams.
Maintenance and Reliability
Periodic inspection of the controller's enclosure and connections helps ensure long service life. Check for dust accumulation that could impede cooling. Verify that all mounting hardware remains tight. The unit's compliance with standards like UL 508 and CE indicates it meets rigorous safety and performance requirements.
Selection Guide and Purchasing Advice
For applications needing a 250 HP motor controller with motion functionality, the 150-F317NBRB delivers proven performance. AutoDCSTech stocks this Allen-Bradley unit to support your industrial automation needs. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 150-F317NBRB |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
