Allen-Bradley 150-F85FCD SMC-Flex Solid State Controller 85A

Technical Specifications Breakdown

Key parameters for the 150-F85FCD are listed below for quick reference:

Application Versatility Across Industries

Its seven standard modes of operation—including Soft Start, Full Voltage Start, Selectable Kickstart, Linear Speed Acceleration, Current Limit Start, Preset Slow Speed, and Dual Ramp Start—allow customization for low or high starting torque requirements. The 150-F85FCD is particularly suited for conveyors, pumps, fans, and compressors where reduced mechanical stress and energy savings are critical. The IP65 enclosure protects against dust and water jets, making it a reliable choice for food processing, automotive, and wastewater treatment plants.

Installation and Setup Guidance

Mount the controller in a clean, dry location with adequate ventilation. Ensure the input line voltage matches the 500-575V AC, 3-phase supply. Connect the control voltage to the 100-240V AC terminals. Use the LCD and backlit keypad to configure parameters such as overload protection, underload protection, overvoltage/undervoltage trip delays (programmable 0-99 seconds), and ground fault protection. Always follow local electrical codes and use appropriately rated conductors.

Maintenance and Reliability Tips

Periodically inspect the enclosure seals and cooling vents to maintain the IP65 rating. Check for signs of overheating or corrosion on terminals. The built-in SCR bypass/contractor reduces heat generation during full-speed operation, extending component life. Monitor motor thermal capacity and power factor via the metering functions to detect early signs of load issues.

Compatibility and Integration

It also controls resistive loads. The programmable overload and underload protection safeguards both the controller and motor wiring. The metering reports elapsed time, power factor, motor thermal capacity in Amps, Volts, kW, kWh, MW, and MWh, enabling integration with plant monitoring systems.

Selection Guide and Purchasing Advice

When selecting a solid state controller, verify that your motor's full-load current and horsepower match the 85 A and 60 Hp @ 460V AC rating. The 150-F85FCD is available at AutoDCSTech, a trusted supplier of industrial automation parts. Please verify current lifecycle status and availability with AutoDCSTech before ordering. Our team can assist with compatibility questions and ensure you receive the correct unit for your application.
